Emerson EV3200 - Chapter 5 Parameter Table (Continued); Communication Parameters (F8)

20 Chapter 5 Parameter Table
EV3200 Door Control Inverter User Manual
Parameter Name Setting range Min. unit Default Mod.
F8.07
CAN communication failure
detection time
0: disable the function
0.1 ~ 100.0s
0.1s 0s ×
F8.08 CAN communication delay 0.01 ~ 1.000s 0.001s 0.01s ×
F8.09 ~ F8.10 Reserved
5.10 Monitoring And Recording Parameters F9
Parameter Name Setting range Min. unit Default Mod.
F9.00 Parameters displayed by LED
The display of each parameter is controlled by a binary bit.
“1” for display:
Bit0: running frequency (Hz)
Bit1: reference frequency (Hz)
Bit2: output voltage (V)
Bit3: output current (A)
Bit4: output torque (%)
Bit5: DC bus voltage (V)
Bit6: Status of input terminal (No unit)
Bit7: Status of output terminal (No unit)
Bit8: low digits of pulse of door position (0 ~ 9999)
Bit9: high digits of pulse of door position (0 ~ 9999)
1
31
(0000011111B)
○
F9.01
Selection of parameters
displayed by LED in stopping
status (blink)
0: preset OD frequency (Hz)
1: preset CD frequency (Hz)
2: status of input terminal (no unit)
3: status of output terminal (no unit)
4: DC bus voltage (V)
5: low digits of pulse counted for door position (0 ~ 9999)
6: high digits of pulse counted for door position (0 ~ 9999)
1 0
○
F9.02
F9.03
F9.04
Type of latest fault
Type of second lastest fault
Type of third lastest fault
0: no fault record
1: Over-current in Acc process (E001)
2: Overcurrent in Dec process (E002)
3: Overcurrent in constant speed operation (E003)
4: Overvoltage in Acc process (E004)
5: Overvoltage in Dec process (E005)
6: Overvoltage in constant speed operation (E006)
7 ~ 8: Reserved
9: Output phase loss (E009)
10: Reserved
11: Heatsink overheating (E011)
12: Reserved
13: Inverter overload (E013)
14: Motor protection (E014)
15: Reserved
16: EEPROM read or write fault (E016)
17: Reserved
18: Reserved
19: Current detecting circuit fault (E019)
20 ~ 23: Reserved
24: Motor tuning error (E024)
25: PG error (E025)
26: Overspeed protection (E026)
27: Reserved
28: Parameter setting error (E028)
29: Door width auto-learning error (E029)
30: OD overtime error (E030)
31: CD overtime error (E031)
1 0 *
F9.05
DC Bus Voltage (V) at the
latest fault
0 ~ 999V 1V 0V *
F9.06
Output current (A) at the latest
fault
0.00 ~ 99.99A 0.01A 0.00A *
