Note
If the actual operation is reverse to OD/CD command, please change the setting of F0.03 or change the phase connection of motor.
5. After testing, set F0.02 to 2 (terminal control mode), and the inverter will begin to work normally.
7.2.3 Parameter Settings
Figure 7-2 provides the parameter settings.
Table 7-2 Parameter settings for speed control
Function code Name Setting Remark
F0.01 Control mode 0 Speed control
F5.00 Function selection for control terminal X1 10 Normally open input contacts for OD speed decrease
F5.01 Function selection for control terminal X2 12 Normally open input contacts for CD speed decrease
F5.02 Function selection for control terminal X3 6 Normally open input for OD position limiting
F5.03 Function selection for control terminal X4 8 Normally open input for CD position limiting
F5.04 Function selection for control terminal X5 2/4
Normally open input contacts for light curtain signal/ safety
edge
F5.05 Function of programmable relay output PA1/PC1 2 Output signal 1 for complete OD
F5.06 Function of programmable relay output PA2/PC2 3 Output signal 1 for complete CD
F1.00 OD start creep time for speed control 500ms
F1.02 OD start creep speed 7Hz
F1.03 OD Acc time 0.5s
F1.04 OD reference frequency 20Hz
F1.05 Rush hour operation OD speed 25Hz
F1.07 OD Dec time 0.5s
F1.08 OD ending creep speed 3Hz
F1.10 Threshold for OD torque changing 50.0%
F1.11 Maintaining torque at OD completion 50.0%
Parameters in this table are factory settings, adjust the OD
parameters according to the actual OD operating
conditions
F2.00 CD start creep time for speed control 500ms
F2.02 CD start creep speed 6Hz
F2.03 CD Acc time 0.5s
F2.04 CD reference frequency 15Hz
F2.05 Rush hour operation CD speed 20Hz
F2.07 CD Dec time 0.5s
F2.08 CD ending creep speed 2Hz
F2.10 Threshold for CD torque changing 50.0%
F2.11 Maintaining torque at CD completion 50.0%
F2.12 CD high speed for EFS 10Hz
Parameters in this table are factory settings, adjust the CD
parameters according to the actual CD operating
conditions
F3.08 CD obstruction sensitivity 100.0%
F3.09 Dec time upon abnormality 300ms
F3.10 OD obstruction sensitivity 100.0%
Parameters in this table are factory settings, adjust the
parameters according to the actual conditions
Note
1. Setting of F3.01 (OD time limit) must be bigger than the sum of time in all phases of OD curve.
2. Setting of F3.02 (CD time limit) must be bigger than the sum of time in all phases of CD curve.
7.3 Distance Control 1
7.3.1 System Wiring Diagram
For distance control 1, PG should be installed on the motor shaft. In distance control, the speed decrease and complete CD
and OD judgments are made according to the actual number of pulses counted. System wiring diagram for distance control is
shown in Figure 7-3 and Figure 7-4.
