Emerson EV3200 - Chapter 5 Parameter Table (Continued); Door Width Self-learning Parameters (F4)

Chapter 5 Parameter Table 17
EV3200 Door Control Inverter User Manual
Parameter Name Setting range Min. unit Default Mod.
F3.17 Fan control
0: fan does not start during inverter
operation
1: fan starts when heatsink temperature is
higher than 65°C during inverter operation
2: fan starts during inverter operation
1 0 ×
F3.18 Percentage or pulse number selection
0: F1.01, F1.06, F1.13, F2.01, F2.06 and
F2.14 are percentages.
1: F1.01, F1.06, F1.13, F2.01, F2.06 and
F2.14 are numbers
0 0 ×
5.5 Door Width Self-learning Parameters F4
Parameter Name Setting range Min. unit Default Mod.
F4.00 PG type
0: 24V incremental PG
1: UVW incremental PG (5V)
1 0
×
F4.01 Pulse number per revolution 0 ~ 4000 1 100 ×
F4.02 PG direction
0: same as direction preset by PG wiring
1: reverse to direction preset by PG wiring
1 0 ×
F4.03 Magnetic pole initial angle 0.0 ~ 359.9° 0.1 0 ×
F4.04 Speed during door width auto-learning 2 ~ 20.00Hz 0.01Hz 5.00 ×
F4.05 Selection of door-width auto-learning
0: disabled
1: enabled
1 0 ×
F4.06 Low digits of pulse count for door wicth 0 ~ 9999 (pulse number) 1 0 ×
F4.07 High digits of pulse count for door width 0 ~ 9999 (×10000) 1 0 ×
F4.08 Actual door width 0 ~ 9999mm 1mm 0mm ×
F4.09
PG cable broken detection time for
asynchronous motor
0 ~ 10s 0.1s 0s ×
F4.10 Ratio of gear 1 ~ 100 1.0 1.0 ×
F4.11 Asynchronous single/dual motor selection
0: single motor control (asynchronous or
synchronous).
1: dual motors control (asynchronous)
0 0 ×
F4.12 Reserved
