44 Chapter 7 Application Guidance
EV3200 Door Control Inverter User Manual
7. Switch on the inverter again, in first time operation (OD or CD), the inverter will operate at the speed set by F3.00. When
the door is opened or closed completely, the inverter will switch to OD (or CD) completion torque maintaining status.
8. Set relevant parameters according to Table 7-4. The CD and OD parameters can be adjusted according to Figure 6-8 and
Figure 6-9.
9. Set F0.02 to 2 (terminal control mode), and the inverter can work normally.
7.5.3 Parameter Settings
Figure 7-4 provides the parameter settings.
Table 7-4 Parameter settings for distance control 3
Function code Name Setting Remark
F0.01 Control mode 1 Distance control 1
F5.00 Function selection for control terminal X1 2 Normally open input contacts for light curtain signal
F5.01 Function selection for control terminal X2 4 Normally open input contacts for safety edge
F5.02 Function selection for control terminal X3 6 Normally open input for OD position limiting
F5.03 Function selection for control terminal X4 8 Normally open input for CD position limiting
F5.05 Function of programmable relay output PA1/PC1 2 Output signal 1 for complete OD
F5.06 Function of programmable relay output PA2/PC2 3 Output signal 1 for complete CD
F1.01 OD start creep distance for distance control 15%
F1.02 OD start creep speed 7Hz
F1.03 OD Acc time 0.5s
F1.04 OD reference frequency 20Hz
F1.05 Rush hour operation OD speed 25Hz
F1.06 OD speed decrease point in distance control 70.0%
F1.07 OD Dec time 0.5s
F1.08 OD ending creep speed 3Hz
F1.09 OD position limit in distance control 95.0%
F1.10 Threshold for OD torque changing 50.0%
F1.11 Maintaining torque at OD completion 50.0%
F1.12 OD operation curve selection in distance control 0
Parameters in this table are factory settings, adjust the
OD parameters according to the actual OD operating
conditions
F2.01 CD start creep distance 15%
F2.02 CD start creep speed 6Hz
F2.03 CD Acc time 0.5s
F2.04 CD reference frequency 15Hz
F2.05 Rush hour operation CD speed 20Hz
F2.06 CD speed decrease point in distance control 70.0%
F2.07 CD Dec time 2.0s
F2.08 CD ending creep speed 2Hz
F2.09 CD position limit in distance control 95.0%
F2.10 Threshold for CD torque changing 50.0%
F2.11 Maintaining torque at CD completion 50.0%
F2.12 CD high speed for EFS 10Hz
F2.13 CD operation curve selection in distance control 0
Parameters in this table are factory settings, adjust the
CD parameters according to the actual CD operating
conditions
F3.00 INI operation speed 5Hz
F3.08 CD obstruction sensitivity 100%
F3.09 Dec time upon abnormality 300ms
F3.10 OD obstruction sensitivity 100%
Parameters in this table are factory settings, adjust the
parameters according to the actual conditions
