Chapter 5 Parameter Table 19
EV3200 Door Control Inverter User Manual
Parameter Name Setting range Min. unit Default Mod.
F6.07 Motor tuning 0: disable 1: enable 1 0 ×
F6.08 Stator resistance 00.00 ~ 99.99ohm 0.01ohm Applicable motor value ×
F6.09 Stator inductance 0 ~ 9999mH 1mH Applicable motor value ×
F6.10 Rotor resistance 00.00 ~ 99.99ohm 0.01ohm Applicable motor value ×
F6.11 Rotor inductance 0 ~ 9999mH 1mH Applicable motor value ×
F6.12 Mutual inductance 0 ~ 9999mH 1mH Applicable motor value ×
F6.13 Exciting current with no load 0.00 ~ 99.99A 0.01A Applicable motor value ×
5.8 Vector Control Parameters F7
Parameter Name Setting range Min. unit Default Mod.
F7.00 ASR proportional gain 1 0.000 ~ 6.000 0.001 0.600 ×
F7.01 ASR integral time 1 0 (integral function disabled), 0.032-32.00s 0.001s 1.000 ×
F7.02 ASR proportional gain 2 0.000 ~ 6.000 0.001 0.600 ×
F7.03 ASR integral time 2 0 (integral function disabled), 0.032-32.00s 0.001s 1.000 ×
F7.04 ASR changing frequency 0.00 ~ 50.0Hz 0.01Hz 5.00 ×
F7.05 Slip compensation gain
0 (reserved), 50.0 ~ 250.0% (for
accounting the slip value)
0.1% 100.0% ×
F7.06 Motoring torque limit 0.0 ~ 200.0% (inverter rated current) 0.1% 100.0% ×
F7.07 Braking torque limit 0.0 ~ 200.0% (inverter rated current) 0.1% 100.0% ×
F7.08 Current loop’s proportional gain KP 0 ~ 9999
1
500
○
F7.09 Current loop’s integral time KI 0 ~ 9999
1
300
○
F7.10 Filtering coefficient 0 ~ 63
1
27
○
5.9 Communication Parameters F8 (Reserved)
Parameter Name Setting range Min. unit Default Mod.
F8.00 Modbus baud rate selection
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
5: 38400bps
6: 76800bps
7: 125000bps
1 4 ×
F8.01 Modbus data format
0: RTU, 1 start bit, 8 data bits, 2 stop bits, no parity
1: RTU, 1 start bit, 8 data bits, 1 stop bit, even parity
2: RTU, 1 start bit, 8 data bits, 1 stop bit, odd parity
3: ASCII, 1 start bit, 7 data bits, 2 stop bits, no parity
4: ASCII, 1 start bit, 7 data bits, 1 stop bit, even parity
5: ASCII, 1 start bit, 7 data bits, 1 stop bit, odd parity
1 0 ×
F8.02 Local number 0 (broadcast address), 1 ~ 127 1 5 ×
F8.03
Modbus communication
failure detection time
0: disable the function
0.1 ~ 100.0s
0.1s 0 ×
F8.04 Modbus communication delay 0.01 ~ 1.000s 0.001s 0.01s ×
F8.05
CAN communication station
enable
Bit0: station 1 enable
Bit1: station 2 enable
Bit2: station 3 enable
Bit3: station 4 enable
Corresponding station =1 means to enable the station
Corresponding station=0 means to disable the station
1
0
×
F8.06 CAN baud rate selection
0: 10000bps
1: 20000bps
2: 40000bps
3: 80000bps
4: 1250000bps
1 0 ×
To Next Page
