S600 Instruction Manual
Table 4-12. PRT/PRD Input Pin Connections for SKT-B
Pin Function
4 PRT-CH1 I+
1 PRT-CH1 V+
21 PRT-CH1 V-
24 PRT-CH1 I-
5 PRT-CH2 I+
2 PRT-CH2 V+
22 PRT-CH2 V-
25 PRT-CH2 I-
6 PRT-CH3 I+
3 PRT-CH3 V+
23 PRT-CH3 V-
26 PRT-CH3 I-
4.1.10 P144 I/O Bit Links (Jumpers)
The boldface entries in the Position column on Table 4-13 are the
default configuration settings. These may not apply to your specific
configuration. Do not change the bit link settings unless told to do so
by the factory.
Note: Point to point communications for the P144 I/O board require
Link 2 to be ON. Multiplex (MUX) communications require Link 2 to
be OFF.
4-14 I/O Revised Jan-07
