S600 Instruction Manual
4.2.6 P154 Prover Bit Links (Jumpers)
The boldface entries in the Position column on Table 4-22 are the
default configuration settings. They may not apply to your specific
configuration.
Table 4-22. P154 Prover Bit Links (Jumpers)
Link Position Descriptions
Flash
LK1 ON Write Enable
OFF
Write Protected
Node Address (see Table 4-23)
LK2 ON
OFF
Multiplexed mode (MUX)
LK11 ON
OFF
Multiplexed mode (MUX)
MUX Address: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
LK3 ● ●
LK4 ● ●
LK5 ● ●
LK6 ● ●
LK7 ● ●
LK8 ● ●
LK9 ● ●
LK10 1-2 ● ● ● ● ● ● ●
2-3 ● ● ● ● ● ● ●
Altera Voltage
LK12 1-2 3.465V
2-3
5V - Vcc
Raw Pulse Output Mode (currently not supported)
LK13/14 1-2 RS-422 differential driver
2-3
Open collector
Raw Pulse Input #3 – Line Determination
LK15/16
ON
Line determination resistors connected: +ve pulled up to Vcc and –ve down to 0V
OFF Lines undetermined
Table 4-23. Node Addressing: Communications Mode Selection
Mode Link 2 Link 11 Link 3-10
Point-to-point ON OFF IGNORED
Multi-dropped ON ON IGNORED
Multiplexed (MUX) OFF OFF ADDRESS
4-24 I/O Revised Jan-07
