Figure 3-2: Activated channel identification
3. (Recommended) Record the channel and wiring configuration on the label provided
inside the transmitter housing cover.
Figure 3-3: Channel and wiring configurations label
3.3 Wire the mA output
Wire the mA output in explosion-proof, nonincendive, or nonhazardous installations.
Important
Meter installation and wiring should be performed only by suitably-trained personnel.
Wiring the channels Installation Manual
October2023 00825-0100-5710
