Emerson Micro Motion Installation Manual

4 Micro Motion
®
Model D and DT Sensors Instruction Manual
Before You Begin continued
D600 sensor with integral booster amplifier and junction box
D600 sensor with integral booster amplifier and core processor
Sensor housing
Booster
amplifier
Process connection
Customer tag
(if requested)
Snub-mount
connector
Junction box
Flow direction
arrow
Calibration tag
Approval tag
Approval tag
Sensor housing
Calibration tag
Flow direction
arrow
Booster amplifier
Core processor
Process connection
Customer tag (if
requested)
Snub mount connector

Emerson Micro Motion Specifications

General

Category	Measuring Instruments
Manufacturer	Emerson
Brand	Micro Motion
Type	Coriolis Flow Meter
Output	4-20 mA, HART, Foundation Fieldbus, Profibus, Modbus
Power Supply	24 V DC
Material	Stainless Steel, Hastelloy
Process Connection	Flanged, Threaded
Certifications	ATEX, IECEx, CSA, SIL
Pressure Rating	Varies by model; up to 10, 000 psi (690 bar)
Temperature Range	Varies by model; -400 to 750°F (-240 to 400°C)
