Micro Motion
®
Model D and DT Sensors Instruction Manual 5
Before You Begin continued
D600 sensor with remote booster amplifier and junction box
D600 sensor with remote booster amplifier and core processor
Approval tag
Sensor housing
Remote booster
amplifier
Process connection
Customer tag
(if requested)
Snub-mount
connector
Junction box
Flow direction
arrow
Calibration tag
Explosion-proof wiring
Intrinsically
safe wiring
Approval tag
Factory-supplied wiring
Approval
tag
Explosion-proof wiring
Intrinsically safe
wiring
Flow
direction
arrow
Core
processor
Sensor housing
Approval tag
Calibration tag
Remote booster
amplifier
Customer tag
(if requested)
Process connection
Snub mount
connector
Factory-supplied wiring

Emerson Micro Motion Specifications

General

Category	Measuring Instruments
Manufacturer	Emerson
Brand	Micro Motion
Type	Coriolis Flow Meter
Output	4-20 mA, HART, Foundation Fieldbus, Profibus, Modbus
Power Supply	24 V DC
Material	Stainless Steel, Hastelloy
Process Connection	Flanged, Threaded
Certifications	ATEX, IECEx, CSA, SIL
Pressure Rating	Varies by model; up to 10, 000 psi (690 bar)
Temperature Range	Varies by model; -400 to 750°F (-240 to 400°C)
