Table 2-7 Keypad identification
Table 2-8 Serial comms lead
Table 2-9 External field control
Automation
(Applications)
Moss Green
SM-Applications
Plus
Applications Processor (with CTNet)
2
nd
processor for running pre-defined and /or customer created
application software with CTNet support. Enhanced
performance over SM-Applications
White
SM-Applications Lite
V2
Applications Processor
2
nd
processor for running pre-defined and /or customer created
application software. Enhanced performance over SM-
Applications Lite
Green brown SM-Register
Applications Processor
2
nd
processor for running position capture functionality with
CTNet support.
Fieldbus
Purple
SM-PROFIBUS DP-
V1
Profibus option
PROFIBUS DP adapter for communications with the drive
Medium Grey SM-DeviceNet
DeviceNet option
Devicenet adapter for communications with the drive
Dark Grey SM-INTERBUS
Interbus option
Interbus adapter for communications with the drive
Light Grey SM-CANopen
CANopen option
CANopen adapter for communications with the drive
Beige SM-Ethernet
Ethernet option
10 base-T / 100 base-T; Supports web pages, SMTP mail and
multiple protocols: DHCP IP addressing; Standard RJ45
connection
Brown Red SM-EtherCAT
EtherCAT option
EtherCAT adapter for communications with the drive
Table 2-6 Solutions Module identification
Type Solutions Module Color Name Further Details
Keypad Name Further Details
SM-Keypad
LED keypad option
Keypad with a LED display
MP-Keypad
LCD keypad option
Keypad with an alpha-numeric LCD display with Help function
Serial comms lead Name Further Details
CT Comms cable
CT EIA (RS) -232 (4500-0087)
CT USB (4500-0096)
External field controller Name Further Details
FXMP25
For external control of field windings up to 25A, with field reversal capability. For further
information, please see the FXMP25 User Guide.
FXMP25
M
STORED CHARGE
10 min
Mode /Reset
