Parameter
Range(
Ú)Default(Ö)
Type
14.01 PID output ±100.00% RO Uni NC PT
14.02 PID source1 Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
14.03 PID source 2 Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
14.04 PID source 3 Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
14.05 PID source invert 1 OFF (0) or On (1) OFF (0) RW Bit US
14.06 PID source invert 2 OFF (0) or On (1) OFF (0) RW Bit US
14.07 PID reference slew rate limit 0 to 3200.0s 0.0 RW Uni US
14.08 PID enable OFF (0) or On (1) OFF (0) RW Bit US
14.09 PID optional enable source Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
14.10 PID P gain 0 to 4.000 1.000 RW Uni US
14.11 PID I gain 0 to 4.000 0.500 RW Uni US
14.12 PID D gain 0 to 4.000 0.000 RW Uni US
14.13 PID upper limit 0 to 100.00% 100.00 RW Uni US
14.14 PID lower limit ±100.00% -100.00 RW Bi US
14.15 PID scaling 0 to 4.000 1.000 RW Uni US
14.16 PID destination Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
14.17 PID hold integrator OFF (0) or On (1) OFF (0) RW Bit NC
14.18 PID symmetrical limit enable OFF (0) or On (1) OFF (0) RW Bit US
14.19 PID main reference ±100.00%
RO Bi NC PT
14.20 PID reference ±100.00%
RO Bi NC PT
14.21 PID feedback ±100.00%
RO Bi NC PT
14.22 PID error ±100.00%
RO Bi NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
