11.10 Menu 10: Status and trips
Parameter
Range(
Ú) Default(Ö)
Type
10.01 Drive ok
OFF (0) or On (1)
RO Bit NC PT
10.02 Drive active RO Bit NC PT
10.03 Zero speed RO Bit NC PT
10.04 Running at or below min speed RO Bit NC PT
10.05 Below set speed RO Bit NC PT
10.06 At speed RO Bit NC PT
10.07 Above set speed RO Bit NC PT
10.08 Load reached RO Bit NC PT
10.09 Drive output is at current limit RO Bit NC PT
10.10 Regenerating RO Bit NC PT
10.13 Direction command RO Bit NC PT
10.14 Direction running RO Bit NC PT
10.17 Overload arm RO Bit NC PT
10.18 Drive over temperature alarm RO Bit NC PT
10.19 Drive warning RO Bit NC PT
10.20 Trip 0 {tr01, 0.51}
0 to 229
RO Txt NC PT PS
10.21 Trip 1 {tr02, 0.52} RO Txt NC PT PS
10.22 Trip 2 {tr03, 0.53} RO Txt NC PT PS
10.23 Trip 3 {tr04, 0.54} RO Txt NC PT PS
10.24 Trip 4 {tr05, 0.55} RO Txt NC PT PS
10.25 Trip 5 {tr06, 0.56} RO Txt NC PT PS
10.26 Trip 6 {tr07, 0.57} RO Txt NC PT PS
10.27 Trip 7 {tr08, 0.58} RO Txt NC PT PS
10.28 Trip 8 {tr09, 0.59} RO Txt NC PT PS
10.29 Trip 9 {tr10, 0.60} RO Txt NC PT PS
10.32 External trip
OFF (0) or On (1) OFF (0)
RW Bit NC
10.33 Drive reset RW Bit NC
10.34 Number of auto-reset attempts 0 to 5 0 RW Uni US
10.35 Auto-reset delay
0 to 25.0s 1.0 RW Uni US
10.36 Hold drive ok until last attempt OFF (0) or On (1) OFF (0) RW Bit US
10.38 User trip 0 to 255 0 RW Uni NC
10.40 Status word 0 to 32767
RO Uni NC PT
10.41 Trip 0 time: Years.Days 0 to 9.364 Years.Days RO Uni NC PT PS
10.42 Trip 0 time: Hours.Minutes 0 to 23.59 Hours.Minutes RO Uni NC PT PS
10.43 Trip 1 time: Hours.Minutes
0 to 600.00 Hours.Minutes
RO Uni NC PT PS
10.44 Trip 2 time: Hours.Minutes RO Uni NC PT PS
10.45 Trip 3 time: Hours.Minutes RO Uni NC PT PS
10.46 Trip 4 time: Hours.Minutes RO Uni NC PT PS
10.47 Trip 5 time: Hours.Minutes RO Uni NC PT PS
10.48 Trip 6 time: Hours.Minutes RO Uni NC PT PS
10.49 Trip 7 time: Hours.Minutes RO Uni NC PT PS
10.50 Trip 8 time: Hours.Minutes RO Uni NC PT PS
10.51 Trip 9 time: Hours.Minutes RO Uni NC PT PS
10.52 Trip mask 0
0 to 216 0
RW Uni US
10.53 Trip mask 1 RW Uni US
10.54 Trip mask 2 RW Uni US
10.55 Trip mask 3 RW Uni US
10.56 Trip mask 4 RW Uni US
10.57 Trip mask 5 RW Uni US
10.58 Trip mask 6 RW Uni US
10.59 Trip mask 7 RW Uni US
10.60 Trip mask 8 RW Uni US
10.61 Trip mask 9 RW Uni US
10.62 Stop on trip mask 0
OFF (0) or On (1)
On (1)
RW Bit US
10.63 Stop on trip mask 1 RW Bit US
10.64 Stop on trip mask 2 RW Bit US
10.65 Stop on trip mask 3 RW Bit US
10.66 Stop on trip mask 4 RW Bit US
10.67 Stop on trip mask 5 RW Bit US
10.68 Stop on trip mask 6 RW Bit US
10.69 Stop on trip mask 7 RW Bit US
10.70 Stop on trip mask 8 RW Bit US
10.71 Stop on trip mask 9 RW Bit US
10.72 Trip mask active
RO Bit NC
10.73 Bridge active 0 to 2 RO Txt NC
10.74 Electrical phase back
OFF (0) or On (1)
RO Bit NC
10.75 Armature voltage clamp active RO Bit NC
10.76 Phase rotation 0 to 15 RO Txt NC
10.77 Input frequency 0 to 100.00 RO Uni NC
