128 Mentor MP User Guide
www.controltechniques.com Issue: 3
Parameter
Range(
Ú) Default(Ö)
Type
12.01 Threshold detector 1 output
OFF (0) or On (1)
RO Bit NC PT
12.02 Threshold detector 2 output RO Bit NC PT
12.03 Threshold detector 1 source Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
12.04 Threshold detector 1 level 0 to 100.00%
0.00
RW Uni US
12.05 Threshold detector 1 hysteresis 0 to 25.00% RW Uni US
12.06 Threshold detector 1 output invert OFF (0) or On (1) OFF (0) RW Bit US
12.07 Threshold detector 1 destination
Pr 0.00 to 22.99 Pr 0.00
RW Uni PT US
12.08 Variable selector 1 source 1 RW Uni PT US
12.09 Variable selector 1 source 2 RW Uni PT US
12.10 Variable selector 1 mode 0 to 10 0 RW Uni US
12.11 Variable selector 1 destination Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
12.12 Variable selector 1 output ±100.00%
RO Uni NC PT
12.13 Variable selector 1 source 1 scaling
±4.000 1.000
RW Uni US
12.14 Variable selector 1 source 2 scaling RW Uni US
12.15 Variable selector 1 control 0 to 100.00 0.00 RW Uni US
12.23 Threshold detector 2 source Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
12.24 Threshold detector 2 level 0 to 100.00%
0.00
RW Uni US
12.25 Threshold detector 2 hysteresis 0 to 25.00% RW Uni US
12.26 Threshold detector 2 output invert OFF (0) or On (1) OFF (0) RW Bit US
12.27 Threshold detector 2 destination
Pr 0.00 to 22.99 Pr 0.00
RW Uni PT US
12.28 Variable selector 2 source 1 RW Uni PT US
12.29 Variable selector 2 source 2 RW Uni PT US
12.30 Variable selector 2 mode 0 to 10 0 RW Uni US
12.31 Variable selector 2 destination Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
12.32 Variable selector 2 output ±100.00%
RO Uni NC PT
12.33 Variable selector 2 source 1 scaling
±4.000 1.000
RW Uni US
12.34 Variable selector 2 source 2 scaling RW Uni US
12.35 Variable selector 2 control 0 to 100.00 0.00 RW Uni US
12.40 Brake release OFF (0) or On (1)
RO Uni NC PT
12.41 Brake controller enable 0 to 3 0 RW Txt US
12.43 Lower current threshold 0 to 150% 10% RW Uni US
12.45 Brake apply speed 0 to 200rpm 5rpm RW Uni US
12.46 Brake apply speed delay
0 to 25.0s 1.0s
RW Uni US
12.47 Post-brake release delay RW Uni US
12.48 Brake apply delay RW Uni US
12.49
Enable position controller during brake
release
OFF (0) or On (1) OFF (0)
RW Bit US
12.50 Field active RW Bit US
12.51 External field control RW Bit US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
