Emerson Rosemount 3051S MultiVariable - IG IECEX FISCO; N7 IECEx Type n; Brazil; E2 INMETRO Flameproof

Quick Start Guide
19
August 2016
Special Conditions for Safe Use (X):
1. If the equipment is fitted with the optional 90 V transient suppressor, it is incapable of
withstanding the 500 V isolation from earth test and this must be taken into account
during installation.
2. The enclosure may be made of aluminum alloy and given a protective polyurethane
paint finish; however, care should be taken to protect it from impact or abrasion if
located in a Zone 0 environment.
IG IECEx FISCO
Certificate: IECEx BAS 08.0025X
Standards: IEC 60079-0:2011, IEC 60079-11:2011
Markings: Ex ia IIC T4 Ga, T4(-60 °C ≤ T
a
≤ +70 °C)
N7 IECEx Type n
Certificate: IECEx BAS 08.0026X
Standards: IEC 60079-0: 2011, IEC 60079-15: 2010
Markings: Ex nA IIC T5 Gc, (-40 °C ≤ T
a
≤ +70 °C)
Special Condition for Safe Use (X):
1. If fitted with a 90 V transient suppressor, the equipment is not capable of withstanding
the 500 V electrical strength test as defined in Clause 6.5.1 of IEC 60079-15:2010. This
must be taken into account during installation.
8.8 Brazil
E2 INMETRO Flameproof
Certificate: UL-BR 15.0393X
Standards: ABNT NBR IEC 60079-0:2008 + Corrigendum 1:2011,
ABNT NBR IEC 60079-1:2009 + Corrigendum 1:2011,
ABNT NBR IEC 60079-26:2008 + Corrigendum 1: 2008
Markings: Ex d IIC T* Ga/Gb, T6(-60 °C ≤ T
a
≤ +70 °C), T5/T4(-60 °C ≤ T
a
≤ +80 °C), IP66
Special Conditions for Safe Use (X):
1. The device contains a thin wall diaphragm. Installation, maintenance and use shall take
into account the environmental conditions to which the diaphragm will be subjected.
The manufacturer’s instructions for installation and maintenance shall be followed in
detail to assure safety during its expected lifetime.
2. For information on the dimensions of the flameproof joints, the manufacturer shall be
contacted.
Parameters HART
FOUNDATION
Fieldbus
SuperModule
only
RTD (for 3051SFx)
HART Fieldbus
Power P
i
1 W 1.3 W 887 mW 17.32 mW 137 mW
Capacitance C
i
14.8 nF 0 0.11 uF 0 0.8 nF
Inductance L
i
0 0 0 0 1.33 mH
Parameters FISCO
Voltage U
i
17.5 V
Current I
i
380 mA
Power P
i
5.32 W
Capacitance C
i
0
Inductance L
i
0
