Figure 3-5 Features of the drive (size B illustrated)
Display
Smart / Logic
Stick slot
Power
terminals
Control
terminals
Serial
communications
port connector
EMC filter tab
Solutions Module
connector
protective cover
(size B
and C only)
Solutions Module
slot (size B, C
and D only)
