140 Unidrive SP Regen Installation Guide
www.controltechniques.com Issue Number: 2
Menu 9 contains 2 logic block functions (which can be used to produce any type of 2 input logic gate, with or without a delay), a motorised pot function
and a binary sum block. One menu 9 or one menu 12 function is executed every 4ms. Therefore the sample time of these functions is 4ms x number
of menu 9 and 12 functions active. The logic functions are active if one or both the sources are routed to a valid parameter. The other functions are
active if the output destination is routed to a valid unprotected parameter.
Table 9-16 Menu 9 Regen parameter descriptions
Parameter
Range(
Ú) Default(Ö)
Type
9.01 Logic function 1 output OFF (0) or On (1) RO Bit NC PT
9.02 Logic function 2 output OFF (0) or On (1) RO Bit NC PT
9.03 Motorised pot output ±100.00 % RO Bi NC PT PS
9.04 Logic function 1 source 1 Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
9.05
Logic function 1 source 1
invert
OFF (0) or On (1) OFF (0) RW Bit US
9.06 Logic function 1 source 2 Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
9.07
Logic function 1 source 2
invert
OFF (0) or On (1) OFF (0) RW Bit US
9.08 Logic function 1 output invert OFF (0) or On (1) OFF (0) RW Bit US
9.09 Logic function 1 delay ±25.0 s 0.0 RW Bi US
9.10 Logic function 1 destination Pr 0.00 to 21.51 Pr 0.00 RW Uni DE PT US
9.14 Logic function 2 source 1 Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
9.15
Logic function 2 source 1
invert
OFF (0) or On (1) OFF (0) RW Bit US
9.16 Logic function 2 source 2 Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
9.17
Logic function 2 source 2
invert
OFF (0) or On (1) OFF (0) RW Bit US
9.18 Logic function 2 output invert OFF (0) or On (1) OFF (0) RW Bit US
9.19 Logic function 2 delay ±25.0 s 0.0 RW Bi US
9.20 Logic function 2 destination Pr 0.00 to 21.51 Pr 0.00 RW Uni DE PT US
9.21 Motorised pot mode 0 to 3 2 RW Uni US
9.22 Motorised pot bipolar select OFF (0) or On (1) OFF (0) RW Bit US
9.23 Motorised pot rate 0 to 250 s 20 RW Uni US
9.24 Motorised pot scale factor 0.000 to 4.000 1.000 RW Uni US
9.25 Motorised pot destination Pr 0.00 to 21.51 Pr 0.00 RW Uni DE PT US
9.26 Motorised pot up OFF (0) or On (1) OFF (0) RW Bit NC
9.27 Motorised pot down OFF (0) or On (1) OFF (0) RW Bit NC
9.28 Motorised pot reset OFF (0) or On (1) OFF (0) RW Bit NC
9.29 Binary sum ones input OFF (0) or On (1) OFF (0) RW Bit NC
9.30 Binary sum twos input OFF (0) or On (1) OFF (0) RW Bit NC
9.31 Binary sum fours input OFF (0) or On (1) OFF (0) RW Bit NC
9.32 Binary sum output 0 to 255 RO Uni NC PT
9.33 Binary sum destination Pr 0.00 to 21.51 Pr 0.00 RW Uni DE PT US
9.34 Binary sum offset 0 to 248 0 RW Uni US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not cloned RA Rating dependent PT Protected US User save PS Power down save
