146 Unidrive SP Regen Installation Guide
www.controltechniques.com Issue Number: 2
9.10 Menu 10: Status and trips
Table 9-17 Menu 10 Regen parameter descriptions
*The value given for the range is that obtained via serial communication. For the text string displayed on the drive, see Table 12.1 Trip indications on
page 206.
Parameter
Range(
Ú) Default(Ö)
Type
10.01 Drive healthy OFF (0) or On (1) RO Bit NC PT
10.02 Drive active OFF (0) or On (1) RO Bit NC PT
10.09 Drive output is at current limit OFF (0) or On (1) RO Bit NC PT
10.10 Regenerating OFF (0) or On (1) RO Bit NC PT
10.11 Braking IGBT active OFF (0) or On (1) RO Bit NC PT
10.12 Braking resistor alarm OFF (0) or On (1) RO Bit NC PT
10.15 Mains loss OFF (0) or On (1) RO Bit NC PT
10.16 Under voltage active OFF (0) or On (1) RO Bit NC PT
10.17 Overload alarm OFF (0) or On (1) RO Bit NC PT
10.18 Drive over temperature alarm OFF (0) or On (1) RO Bit NC PT
10.19 Drive warning OFF (0) or On (1) RO Bit NC PT
10.20 Trip 0 0 to 230* RO Txt NC PT PS
10.21 Trip 1 0 to 230* RO Txt NC PT PS
10.22 Trip 2 0 to 230* RO Txt NC PT PS
10.23 Trip 3 0 to 230* RO Txt NC PT PS
10.24 Trip 4 0 to 230* RO Txt NC PT PS
10.25 Trip 5 0 to 230* RO Txt NC PT PS
10.26 Trip 6 0 to 230* RO Txt NC PT PS
10.27 Trip 7 0 to 230* RO Txt NC PT PS
10.28 Trip 8 0 to 230* RO Txt NC PT PS
10.29 Trip 9 0 to 230* RO Txt NC PT PS
10.30 Full power braking time 0.00 to 400.00 s
See Pr
10.30 on page 149
RW Uni US
10.31 Full power braking period 0.0 to 1500.0 s
Size 1 and 2: 2.0
Size 3 upwards: 0.0
RW Uni US
10.32 External trip OFF (0) or On (1) OFF (0) RW Bit NC
10.33 Drive reset OFF (0) or On (1) OFF (0) RW Bit NC
10.34 No. of auto-reset attempts 0 to 5 0 RW Uni US
10.35 Auto-reset delay 0.0 to 25.0 s 1.0 RW Uni US
10.36
Hold drive healthy until last
attempt
OFF (0) or On (1) OFF (0) RW Bit US
10.37 Action on trip detection 0 to 3 0 RW Uni US
10.38 User trip 0 to 255 0 RW Uni US
10.40 Status word 0 to 32,767 RO Uni NC PT
10.41 Trip 0 time: years.days 0.000 to 9.365 years.days RO Uni NC PT PS
10.42 Trip 0 time: hours.minutes 00.00 to 23.59 hours.minutes RO Uni NC PT PS
10.43 Trip 1 time 0 to 600.00 hours.minutes RO Uni NC PT PS
10.44 Trip 2 time 0 to 600.00 hours.minutes RO Uni NC PT PS
10.45 Trip 3 time 0 to 600.00 hours.minutes RO Uni NC PT PS
10.46 Trip 4 time 0 to 600.00 hours.minutes RO Uni NC PT PS
10.47 Trip 5 time 0 to 600.00 hours.minutes RO Uni NC PT PS
10.48 Trip 6 time 0 to 600.00 hours.minutes RO Uni NC PT PS
10.49 Trip 7 time 0 to 600.00 hours.minutes RO Uni NC PT PS
10.50 Trip 8 time 0 to 600.00 hours.minutes RO Uni NC PT PS
10.51 Trip 9 time 0 to 600.00 hours.minutes RO Uni NC PT PS
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not cloned RA Rating dependent PT Protected US User save PS Power down save
