Unidrive SP Regen Installation Guide 25
Issue Number: 2 www.controltechniques.com
3.9 Items supplied with the drive
The drive is supplied with a copy of the Unidrive SP Short Form Guide, a
SMARTCARD, the safety booklet, the certificate of quality, an accessory
kit box (see the Unidrive SP User Guide for details) and a CD ROM
containing the following user guides:
• Unidrive SP User Guide (English, French, German, Italian, Spanish)
• Unidrive SP Advanced User Guide
• Unidrive SP Regen Installation Guide
• Solutions Module User Guides
• Unidrive SPM User Guide
3.10 Regen components
3.10.1 Regen inductor
The regen inductor supports the difference between the PWM voltage
from the Unidrive SP Regen drive and sinusoidal voltage from the
supply.
Table 3-12 200V (200V to 240V ± 10%) Regen Inductors
Table 3-13 400V (380V to 480V ± 10%) Regen Inductor
Table 3-14 575V (500V to 575V ± 10%) Regen Inductor
The following regen inductors are special parts being
designed for very high levels of harmonic voltage and having
a high saturation current with good linearity below saturation.
Under no circumstances must a part be used other than
those listed.
Drive
Part number mH Arms
Heavy Duty Normal Duty
SP1203 SP1203 4401-0310 3.50 9.6
SP1204 SP1204 4401-0311 2.70 11.0
SP2201 SP2201 4401-0312 2.20 15.5
SP2202 SP2202 4401-0313 1.60 22.0
SP2203 SP2203 4401-0314 1.10 31.0
SP3201
4401-0314 1.10 31.0
SP3202 SP3201 4401-0315 0.81 42.0
SP4201 SP3202 4401-0316 0.60 56.0
SP4202 SP4201 4401-0317 0.50 68.0
SP4203 SP4202 4401-0318 0.40 80.0
SP5201 SP4203 4401-0319 0.32 105.0
SP5202 SP5201 4401-0320 0.26 130.0
SPMD1201 SP5202 4401-0321 0.22 156.0
SPMD1202 SPMD1201 4401-0322 0.18 192.0
SPMD1203 SPMD1202 4401-0323 0.14 250.0
SPMD1204 SPMD1203 4401-0324 0.11 312.0
SPMD1204 4401-0325 0.10 350.0
CAUTION
Drive
Part number mH Arms
Heavy Duty Normal Duty
SP1405 SP1405 4401-0001 6.30 9.5
SP1406
4401-0001 6.30 9.5
SP1406 4401-0002 5.00 12.0
SP2401 SP2401 4401-0003 3.75 16.0
SP2402
4401-0003 3.75 16.0
SP2403 SP2402 4401-0004 2.40 25.0
SP2404 SP2403 4401-0005 1.76 34.0
SP3401 SP2404 4401-0005 1.76 34.0
SP3402 SP3401 4401-0006 1.50 40.0
SP3403 SP3402 4401-0007 1.30 46.0
SP4401 SP3403 4401-0008 1.00 60.0
SP4401 4401-0009 0.78 70.0
SP4402 SP4402 4401-0010 0.63 96.0
SP4403
4401-0010 0.63 96.0
SP5401 SP4403 4401-0011 0.48 124.0
SP5402 SP5401 4401-0012 0.38 156.0
SP6401 SP5402 4401-0013 0.33 180.0
SP6402 SP6401 4401-0014 0.30 200.0
SP6402 4401-0015 0.20 300.0
SPMA1401
4401-0013 0.33 180.0
SPMA1402 SPMA1401 4401-0014 0.30 200.0
SPMA1402 4401-0015 0.20 300.0
SPMD1401
4401-0013 0.33 180.0
SPMD1402 SPMD1401 4401-0014 0.30 200.0
SPMD1402 4401-0015 0.20 300.0
SPMD1403 SPMD1403 4401-0015 0.20 300.0
SPMD1404
4401-0015 0.20 300.0
SPMD1404 4401-0205-00 0.16 350.0
Drive
Part number mH Arms
Heavy Duty Normal Duty
SP3505 SP3505 4401-0210 5.30 19.0
SP3506
4401-0211 4.60 22.0
SP3507 SP3506 4401-0212 3.80 27.0
SP3507 4401-0212 3.80 27.0
SP4601
4401-0211 4.60 22.0
SP4602 SP4601 4401-0212 3.80 27.0
SP4603 SP4602 4401-0212 3.80 27.0
SP4604 SP4603 4401-0213 2.80 36.0
SP4605 SP4604 4401-0214 2.40 43.0
SP4606 SP4605 4401-0215 1.90 52.0
SP5601 SP4606 4401-0216 1.60 63.0
SP5602 SP5601 4401-0217 1.20 85.0
SP6601 SP5602 4401-0218 1.00 100.0
SP6602 SP6601 4401-0219 0.80 125.0
SPMA1601
4401-0218 1.00 100.0
SPMD1601
4401-0218 1.00 100.0
SPMA1602 SPMA1601 4401-0219 0.80 125.0
SPMD1602 SPMD1601 4401-0219 0.80 125.0
SPMA1602 4401-0220 0.70 144.0
SPMD1602 4401-0220 0.70 144.0
SPMD1603 SP6602 4401-0220 0.70 144.0
SPMD1604 SPMD1603 4401-0221 0.60 168.0
SPMD1604 4401-0222 0.53 192.0
