12.01 Threshold detector 1 output
12.02 Threshold detector 2 output
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Update rate 4ms x number of menu 9 or 12 functions active
12.03 Threshold detector 1 source
12.23 Threshold detector 2 source
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Regen Pr 0.00 to Pr 21.51
Default Regen Pr 0.00
Update rate Background
12.04 Threshold detector 1 level
12.24 Threshold detector 2 level
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 111
Range Regen 0.00 to 100.00 %
Default Regen 0.00
Update rate 4ms x number of menu 9 or 12 functions active
12.05 Threshold detector 1 hysteresis
12.25 Threshold detector 2 hysteresis
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 111
Range Regen 0.00 to 25.00 %
Default Regen 0.00
Update rate 4ms x number of menu 9 or 12 functions active
12.06 Threshold detector 1 output invert
12.26 Threshold detector 2 output invert
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
