Emerson SP3402 - Size 2 External EMC Filter

Safety
Information
Introduction
Product
information
System
design
Mechanical
installation
Electrical
installation
Getting
started
Optimisation Parameters
Technical
data
Component
sizing
Diagnostics
Unidrive SP Regen Installation Guide 57
Issue Number: 2 www.controltechniques.com
Figure 5-22 Size 2 external EMC filter
All filter mounting holes are suitable for M6 fasteners.
V: Ground stud: M5
X: M6 threaded holes for footprint mounting of the drive
Y: Footprint mounting holes 6.5mm (0.256in)
Z: Bookcase mounting slots 6.5mm (0.256in) wide
∅
Y
ED
Z
L2
L1
L3
L
1
'
L
2
'
L
3
'
V
X
Y
Y
A
B
H
CW
Z
Z
Cable size:
4mm
10AWG
2
CT part no. Manufacturer A B C D E H W
4200-6210 Schaffner
371.5 mm
(14.626 in)
404.5 mm
(15.925 in)
125 mm
(4.921 in)
55 mm
(2.165 in)
30 mm
(1.181 in)
428.5 mm
(16.870 in)
155 mm
(6.102 in)
4200-6211 Epcos
431.5 mm
(16.988 in)
