The binary sum output is given by:
Offset + ones input + (2 x twos input) + (4 x fours input)
The value written to the destination parameter is defined as follows:
If destination parameter maximum ≤ (7 + Offset):
Destination parameter = Binary sum output
If destination parameter maximum > (7 + Offset):
Destination parameter = Destination parameter maximum x Binary sum output / (7 + Offset)
9.31 Binary sum fours input
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
9.32 Binary sum output
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range Regen 0 to 255
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
9.33 Binary sum destination
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Regen Pr 0.00 to Pr 21.51
Default Regen Pr 0.00
Update rate Background
9.34 Binary sum offset
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Regen 0 to 248
Default Regen 0
Update rate 4ms x number of menu 9 or 12 functions active
