76 Unidrive SP Regen Installation Guide
www.controltechniques.com Issue Number: 2
Table 6-3 Size 4, 5, 6 and the SPM input current, fuse and cable size ratings (universal)
Table 6-4 Unidrive SPMD input current, fuse and cabling ratings
Model
Maximum
continuous
input
current
A
IEC class gR OR
North
American Ferraz HSJ
HRC AND
Semi-conductor Cable size
IEC class
gR
North American
Ferraz HSJ
HRC IEC class gG
UL class J
Semi- Conductor
IEC class aR
mm
2
AWG
SP4201 68 100 90 90 160 25 3
SP4202 80 100 100 100 160 35 3
SP4203 104 125 125 125 200 70 1
SP5201 130 200 175 160 200 95 210
SP5202 154 250 225 200 250 120 410
SP4401 68 80 80 80 160 25 3
SP4402 83 110 110 100 200 35 2
SP4403 104 125 125 125 200 70 1
SP5401 138 200 175 160 200 95 2/0
SP5402 168 250 225 200 250 120 4/0
SP6401 205 250 250 250 315 2 x 70 2 x 2/0
SP6402 236 315 300 300 350 2 x 120 2 x 4/0
SPMA1401 205 315 300 250 315 2 x 70 2 x 2/0
SPMA1402 246 315 300 300 350 2 x 120 2 x 4/0
SPMD1201 192
Refer to SPMC
SPMD1202 248
SPMD1203 312
SPMD1204 350
SPMD1401 205
Refer to SPMC
SPMD1402 246
SPMD1403 290
SPMD1404 350
SP4601 22 63 60 32 125 4 10
SP4602 27 63 60 40 125 6 8
SP4603 36 63 60 50 125 10 8
SP4604 43 63 60 50 125 16 6
SP4605 52 63 60 63 125 16 6
SP4606 62 80 60 63 125 25 4
SP5601 84 125 100 90 160 35 2
SP5602 99 125 100 125 160 50 1
SP6601 125 160 175 150 315 2 x 50 2 x 1
SP6602 144 160 175 160 315 2 x 50 2 x 1
SPMA1601 125 200 200 200 200 2 x 50 2 x 1
SPMA1602 144 200 200 200 200 2 x 50 2 x 1
SPMD1601 125
Refer to SPMC
SPMD1602 144
SPMD1603 168
SPMD1604 192
Model
Typical DC
Input current
A
Maximum DC
Input current
A
Maximum DC
Input voltage
Vdc
DC fuse
IEC class aR
A
DC Cable size
mm
2
AWG
SPMD1401 222 343 800 400 2 x 70 2 x 2/0
SPMD1402 268 400 800 560 2 x 95 2 x 4/0
SPMD1403 314 457 800 560 2 x 120 2 x 4/0
SPMD1404 379 552 800 560 2 x 120 2 x 4/0
SPMD1601 135 191 1150 250 2 x 95 2 x 4/0
SPMD1602 157 240 1150 315 2 x 120 2 x 4/0
SPMD1603 184 275 1150 350 2 x 120 2 x 4/0
SPMD1604 209 323 1150 400 2 x 120 2 x 4/0
