Emerson SP4403 - Optional External EMC Filters

Safety
Information
Introduction
Product
information
System
design
Mechanical
installation
Electrical
installation
Getting
started
Optimisation Parameters
Technical
data
Component
sizing
Diagnostics
Unidrive SP Regen Installation Guide 199
Issue Number: 2 www.controltechniques.com
10.4.4 Switching frequency filter capacitors
The capacitors specified below are suitable for operation at any switching frequency. These being sized for operation at 3kHz, however, operation
above 3kHz is possible with the capacitors being more effective.
Table 10-29 200V Switching frequency filter capacitor
Table 10-30 400V Switching frequency filter capacitor
Table 10-31 575V / 690V Switching frequency filter capacitor
Switching frequency filter capacitor specification
Overload - I
max
= 1.3 x I
rated
I
inrush
= 200 x I
rated
Switching frequency filter capacitor MCB
The 3-phase switching frequency filter capacitors can absorb harmonics
from the supply or notching currents from DC drives which can result in
spurious tripping of the MCB. Therefore considerations must be made to
the supply when sizing the MCB, if these are present at high levels. In
this situation consult the drive supplier for advice.
10.5 Optional external EMC filters
Table 10-32 Unidrive SP / EMC filter cross reference
Capacitor part
no.
Capacitance
uF
I
rated
A
Max ∅
mm
Max L
mm
Weight
kg
Fixing stud
mm
Discharge resistor
Ω
1664-1074 7 1.7 53 114 0.3 M 12 @ 15Nm 390k
1664-2174 17 4.3 116.2 204 0.4 M 12 @ 10Nm 390k
1665-8324 32 11 116.2 204 1.3 M 12 @ 10Nm 390k
1664-2644 64 16.6 116.2 204 1.2 M 12 @ 10Nm 390k
Capacitor part
no.
Capacitance
uF
I
rated
A
Max ∅
mm
Max L
mm
Weight
kg
Fixing stud
mm
Discharge resistor
Ω
1610-7804 8 2.64 82 204 0.5 M 12 @ 15Nm 390k
1665-8324 32 11.0 121 204 1.1 M 12 @ 10Nm 390k
1665-8484 48 14.0 121 204 1.3 M 12 @ 10Nm 390k
1665-8774 77 24.0 121 204 1.5 M 12 @ 10Nm 390k
1665-8394 39 20 121 204 1.5 M 12 @ 10Nm 390k
Capacitor part
no.
Capacitance
uF
I
rated
A
Max ∅
mm
Max L
mm
Weight
kg
Fixing stud
mm
Discharge resistor
Ω
1666-8113 11 5 116.2 204 1.3 M 12 @ 10Nm 390k
1666-8223 23 10 116.2 204 1.4 M 12 @ 10Nm 390k
1668-7833 8.3 7.3 116.2 204 1.2 M 12 @ 10Nm 390k
1668-8163 16.6 12.4 116.2 204 1.2 M 12 @ 10Nm 390k
The 3-phase switching frequency filter capacitors are
situated on the input of the regen system. As a result the
capacitor can also absorb harmonics if present from the
supply, and in worst case conditions result in the capacitors
running hot or even failure.
An MCB should be fitted between the AC supply and the 3-
phase switching frequency filter capacitor. This is to protect
the capacitor and the wiring to the mains busbar from
damage by faults or overloads.
CAUTION
CAUTION
NOTE
Drive
Schaffner Epcos
CT part no. CT part no.
SP1201 to SP1202 4200-6118 4200-6121
SP1203 to SP1204 4200-6119 4200-6120
SP2201 to SP2203 4200-6210 4200-6211
SP3201 to SP3202 4200-6307 4200-6306
SP4201 to SP4203 4200-6406 4200-6405
SP5201 to SP5202 4200-6503 4200-6501
SPMD1201 to SPMD1204 4200-6315 4200-6313
SP1401 to SP1404 4200-6118 4200-6121
SP1405 to SP1406 4200-6119 4200-6120
SP2401 to SP2404 4200-6210 4200-6211
SP3401 to SP3403 4200-6305 4200-6306
SP4401 to SP4403 4200-6406 4200-6405
SP5401 to SP5402 4200-6503 4200-6501
SP6401 to SP6402 4200-6603 4200-6601
SP3501 to SP3507 4200-6309 4200-6308
SP4601 to SP4606 4200-6408 4200-6407
SP5601 to SP5602 4200-6504 4200-6502
SP6601 to SP6602 4200-6604 4200-6602
SPMA1401 to SPMA1402 4200-6603 4200-6601
SPMD1401 to SPMD1404 4200-6315 4200-6313
SPMA1601 to SPMA1602 4200-6604 4200-6602
SPMD1601 to SPMD1604 4200-6316 4200-6314
