Output current
The continuous output current ratings given on the rating label are for maximum 40 °C (104 °F),
1000 m altitude and 3.0 kHz switching frequency. Derating is required for higher switching
frequencies, ambient temperatures >40 °C (104 °F) and higher altitude. For derating information,
refer to the Drive User Guide.
Input current
The input current is affected by the supply voltage and impedance. The input current given on the
rating label is the typical input current and is stated for a balanced supply.
Input line reactor (Frame 9E and 10)
A line reactor must be used with Frame 9E and 10. Failure to provide sufficient reactance could
damage or reduce the service life of the drive. Refer to Table 2-7 below.
Table 2-7 Size 9E and 10 model and line reactor part number
* This may represent a more economical solution where operating temperature and cooling
requirements are observed. Refer to the Drive User Guide for further information.
The maximum overload level which can be attained is independent of the speed.
Size Drive model Inductor model
Line reactor
part number
9
09201760, 09202190, 09402000, 09402240
INL 401 4401-0181
INL 401W* 4401-0208
09501040, 09501310, 09601040, 09601310 INL 601 4401-0183
10
10202830, 10203000, 10402700, 10403200
INL 402 4401-0182
INL 402W* 4401-0209
10501520, 10501900, 10601500, 10601780 INL 602 4401-0184
