Model Number Nomenclature—All Systems
Liebert
®
Mini-Mate2
™
4
Figure 5 Model number nomenclature—Chilled water units
MM
D = Disconnect Switch
0 = No Disconnect Switch
Liebert Mini-Mate2
Valve Type
2 = 2-Way Valve (Std Close-off)
D = 2-Way Valve (High Close-off)
Humidification
H = Canister Humidifier
0 = No Humidifier
R = Remote Humidifier Contact
J = Canister Humidifier and Remote
Humidifier Contact
D23 2 P H A
Reheat Type
0 = No Reheat
E = Electric Reheat
H = Hot Water Reheat
Supply Power
P = 208/230-1-60
X = 277-1-60
S = 220-1-50
C E0
Unit Type
C = Chilled Water
Hot Gas Bypass
0 = Not Contained in Unit
Nominal Capacity, kBtuh
23 (60Hz)
22 (50Hz)
Sensor Packages
0 = None
A = Filter Clog
B = Smoke Sensor
C = High-Temperature Sensor
D = Filter Clog and Smoke Sensor
E = Filter Clog and High-Temperature Sensor
F = Smoke Sensor and High-Temperature Sensor
G = Filter Clog, Smoke Sensor and High-Temperature Sensor
