Emerson XC1015D

1592021021 XC1008-1011-1015D GB A5 r.1.5A 12.10.2009 XC1008-1011-1015D 59/66
Nome XC
1008
D
XC
1011
D
XC
1015
D
Level
Description Range
C34
404 0 0 Pr2 Kind of gas 0 ÷ 255
C35
60 0 0 Pr2 Screw compressors' second step
activation delay
0 ÷ 255
C36
NO 0 0 Pr2 Screw compressors' first step used in
regulation
0 ÷ 255
C37
db 0 0 Pr2 Regulation for compressor circuit 1 0 ÷ 255
C38
- 0 0 Pr2 Regulation for compressor circuit 2 0 ÷ 255
C41
YES 0 0 Pr2 Compressor rotation circuit 1 0 ÷ 255
C42
- 0 0 Pr2 Compressor rotation circuit 2 0 ÷ 255
C45
YES 0 0 Pr2 Fan rotation circuit 1 0 ÷ 255
C44
- 0 0 Pr2 Fan rotation circuit 2 0 ÷ 255
C45
C / dec
0 0 Pr2 Displaying measurement unit 0 ÷ 255
C46
rEL 0 0 Pr2 Pressure display (rel/abs) 0 ÷ 255
AI1
Cur Cur Cur Pr2 Kind of probe of P1 & P2 Cur(0) - Ptc(1) - ntc(2) - rAt(3)
AI2
-0,5 -0.50 -0.50 Pr2 Probe 1 readout at 4mA/0V (-1.00 ÷ AI3)
BAR
(-15 ÷ AI3)
PSI
AI3
11,0 11.00 11.00 Pr2 Probe 1 readout at 20mA/5V (AI2 ÷ 100.00)
BAR
(AI2 ÷ 750)
PSI
AI4
0,0 0.0 0.0 Pr2 Probe 1 calibration
(dEU=bar o °C)
-12.0 ÷ 12.0
(dEU=PSI o °F)
-120 ÷
120
AI5
- -0.50 -0.50 Pr2 Probe 2 readout at 4mA/0V (-1.00 ÷ AI6)
BAR
(-15 ÷ AI6)
PSI
AI6
- 11.00 11.00 Pr2 Probe 2 readout at 20mA/5V (AI5 ÷ 100.00)
BAR
(AI5 ÷ 750)
PSI
AI7
- 0.0 0.0 Pr2 Probe 2 calibration
(dEU=bar o °C)
-12.0 ÷ 12.0
(dEU=PSI o °F)
-120÷120
AI8
Cur Cur Cur Pr2 Kind of probe of P3 & P4 Cur(0) - Ptc(1) - ntc(2) - rAt(3)
AI9
0,0 0.00 0.00 Pr2 Probe 3 readout at 4mA/0V (-1.00 ÷ AI10)
BAR
(-15 ÷ AI10)
PSI
AI10
30,0 30.00 30.00 Pr2 Probe 3 readout at 20mA/5V (AI9 ÷ 100.00)
BAR
(AI9 ÷ 750)
PSI
AI11
0,0 0.0 0.0 Pr2 Probe 3 calibration
(dEU=bar o °C)
-12.0 ÷ 12.0
(dEU=PSI o °F)
-120 ÷
120
AI12
- 0.00 0.00 Pr2 Probe 4 readout at 4mA/0V (-1.00 ÷ AI13)
BAR
(-15 ÷ AI13)
PSI
AI13
- 30.00 30.00 Pr2 Probe 4 readout at 20mA/5V (AI12 ÷ 100.00)
BAR
(AI12 ÷ 750)
PSI
AI14
- 0.0 0.0 Pr2 Probe 4 calibration
(dEU=bar o °C)
-12.0 ÷ 12.0
(dEU=PSI o °F)
-120 ÷
120
AI15
ALr ALr ALr Pr2 Alarm relay for regulation faulty probe nu - ALr - ALr1 - ALr2
AI16
ntc Ntc Ntc Pr1 Probe 5 setting (ntc/ptc) ptc(0) - ntc(1)
AI17
nu nu nu Pr1 Probe 5 action type nu = not used ;
Au1 = Probe for AUX1 thermostat;
Au2 = Probe for AUX2 thermostat;
Au3 = Probe for AUX3 thermostat;
Au4 = Probe for AUX4 thermostat;
otC1 = dynamic set point for delivery – circuit 1
otC2 = dynamic set point for delivery – circuit 2
otA1 = dynamic set point for suction – circuit 1
otA2 = dynamic set point for suction – circuit 2
AI18
0,0 0.0 0.0 Pr1 Probe 5 calibration
(dEU=bar o °C)
-12.0 ÷ 12.0
(dEU=PSI o °F)
-120 ÷
120
AI19
ntc Ntc Ntc Pr1 Probe 6 setting (ntc/ptc) ptc(0) - ntc(1)
AI20
nu nu nu Pr1 Probe 6 action type nu = not used ;
Au1 = Probe for AUX1 thermostat;
Au2 = Probe for AUX2 thermostat;
Au3 = Probe for AUX3 thermostat;
Au4 = Probe for AUX4 thermostat;
otC1 = dynamic set point for delivery – circuit 1
otC2 = dynamic set point for delivery – circuit 2
otA1 = dynamic set point for suction – circuit 1
otA2 = dynamic set point for suction – circuit 2
AI21
0,0 0.0 0.0 Pr1 Probe 6 calibration
(dEU=bar o °C)
-12.0 ÷ 12.0
(dEU=PSI o °F)
-120 ÷
120
AI22
ntc Ntc Ntc Pr1 Probe 7 setting (ntc/ptc) ptc(0) - ntc(1)
