Nome XC
1008
D
XC
1011
D
XC
1015
D
Level
Description Range
AI23
nu nu nu Pr1 Probe 7 action type nu = not used ;
Au1 = Probe for AUX1 thermostat;
Au2 = Probe for AUX2 thermostat;
Au3 = Probe for AUX3 thermostat;
Au4 = Probe for AUX4 thermostat;
otC1 = dynamic set point for delivery – circuit 1
otC2 = dynamic set point for delivery – circuit 2
otA1 = dynamic set point for suction – circuit 1
otA2 = dynamic set point for suction – circuit 2
AI24
0,0 0.0 0.0 Pr1 Probe 7 calibration
(dEU=bar o °C)
-12.0 ÷ 12.0
(dEU=PSI o °F)
-120 ÷
120
AI25
ntc Ntc Ntc Pr1 Probe 8 setting (ntc/ptc) ptc(0) - ntc(1)
AI26
nu nu nu Pr1 Probe 8 action type nu = not used ;
Au1 = Probe for AUX1 thermostat;
Au2 = Probe for AUX2 thermostat;
Au3 = Probe for AUX3 thermostat;
Au4 = Probe for AUX4 thermostat;
otC1 = dynamic set point for delivery – circuit 1
otC2 = dynamic set point for delivery – circuit 2
otA1 = dynamic set point for suction – circuit 1
otA2 = dynamic set point for suction – circuit 2
AI27
0,0 0.0 0.0 Pr1 Probe 8 calibration
(dEU=bar o °C)
-12.0 ÷ 12.0
(dEU=PSI o °F)
-120 ÷
120
AI28
ALr ALr ALr Pr1 Alarm relay for AUX faulty probe nu - ALr - ALr1 - ALr2
DI2
cL CL CL Pr2 LP swtich polarity - circuit 1 OP - CL
DI3
- CL CL Pr2 LP swtich polarity - circuit 2 OP - CL
DI4
cL CL CL Pr2 HP swtich polarity - circuit 1 OP - CL
DI5
- CL CL Pr2 HP swtich polarity - circuit 2 OP - CL
DI6
ALr ALr ALr Pr2 Relay for pressure switch alarm nu - ALr - ALr1 - ALr2
DI7
cL CL CL Pr2 Safe input polarity compressor circuit 1 OP - CL
DI8
- CL CL Pr2 Safe input polarity compressor circuit 2 OP - CL
DI9
cL CL CL Pr2 Safety input polarity fan circuit 1 OP - CL
DI10
- CL CL Pr2 Safety input polarity fan circuit 2 OP - CL
DI11
no NO NO Pr2 Manual restart for compressor alarm no - YES
DI12
no NO NO Pr2 Manual restart for fan alarm no - YES
DI13
ALr ALr ALr Pr2 Relay for compressor or fan alarm nu - ALr - ALr1 - ALr2
DI14
CL CL CL Pr1 Polarity of configurable digital input 1 OP - CL
DI15
LL1 LL1 LL1 Pr1 Function of configurable digital input 1 ES1 - ES2 - OFF1 - OFF2 - LL1 - LL2 -noCRO
- noSTD1- noSTD2
DI16
10 20 20 Pr1 Delay of configurable digital input 1 0 ÷ 255 (min)
DI17
CL CL CL Pr1 Polarity of configurable digital input 2 OP - CL
DI18
ES1 ES1 ES1 Pr1 Function of configurable digital input 2 ES1 - ES2 - OFF1 - OFF2 - LL1 - LL2 -noCRO
- noSTD1- noSTD2
DI19
0 0 0 Pr1 Delay of configurable digital input 2 0 ÷ 255 (min)
DI20
CL CL CL Pr1 Polarity of configurable digital input 3 OP - CL
DI21
LL2 LL2 LL2 Pr1 Function of configurable digital input 3 ES1 - ES2 - OFF1 - OFF2 - LL1 - LL2 -noCRO
- noSTD1- noSTD2
DI22
0 20 20 Pr1 Delay of configurable digital input 3 0 ÷ 255 (min)
DI23
CL CL CL Pr1 Polarity of configurable digital input 4 OP - CL
DI24
ES2 ES2 ES2 Pr1 Function of configurable digital input 4 ES1 - ES2 - OFF1 - OFF2 - LL1 - LL2 -noCRO
- noSTD1- noSTD2
DI25
0 0 0 Pr1 Delay of configurable digital input 4 0 ÷ 255 (min)
DI26
ALr ALr ALr Pr1 Relay for LL alarm - circuit 1 nu - ALr - ALr1 - ALr2
DI27
- ALr ALr Pr1 Relay for LL alarm - circuit 2 nu - ALr - ALr1 - ALr2
CP1
4.0 4.0 4.0 Pr1 Regulation band width circuit 1
(BAR)
0.10÷10.00
(°C)
0.0÷25.0
(PSI)
1÷80
(°F)
1÷50
