Nome XC
1008
D
XC
1011
D
XC
1015
D
Level
Description Range
CP2
-40,0 -40.0 -40.0 Pr1 Minimum set point circuit 1 BAR: (AI2 ÷ SETC1); °C: (-50.0 ÷ SETC1);
PSI : (AI2 ÷ SETC1); °F : (-58.0 ÷ SETC1)
CP3
10,0 10.0 10.0 Pr1 Maximum set point circuit 1 BAR: (SETC1÷AI3); °C : (SETC1 ÷ 150.0);
PSI : (SETC1 ÷ AI3); °F: (SETC1 ÷ 302)
CP4
0 0.0 0.0 Pr1 Energy saving circuit 1
(BAR)
-20.00÷20.00
(°C)
-50.0÷50.0
(PSI)
-300÷300
(°F)
-90÷90
CP5
- 5.0 5.0 Pr1 Regulation band width circuit 2
(BAR)
0.10÷10.00
(°C)
0.0÷25.0
(PSI)
1÷80
(°F)
1÷50
CP6
- -40.0 -40.0 Pr1 Minimum set point circuit 2 BAR: (AI5 ÷ SETC2); °C: (-50.0 ÷ SETC2);
PSI : (AI5 ÷ SETC2); °F : (-58.0 ÷ SETC2)
CP7
- 10.0 10.0 Pr1 Maximum set point circuit 2 BAR: (SETC2÷AI6); °C : (SETC2 ÷ 150.0);
PSI : (SETC2 ÷ AI6); °F: (SETC2 ÷ 302)
CP8
- 0.0 0.0 Pr1 Energy saving circuit 2
(BAR)
-20.00÷20.00
(°C)
-50.0÷50.0
(PSI)
-300÷300
(°F)
-90÷90
CP9
5 5 5 Pr1 2 start compressor delay 0 ÷ 255 (min)
CP10
2 2 2 Pr1 Minimum time load off 0 ÷ 255 (min)
CP11
15 15 15 Pr1 2 different load start delay 0 ÷ 99.5 (min.1sec)
CP12
5 5 5 Pr1 2 different load off delay 0 ÷ 99.5 (min.1sec)
CP13
15 15 15 Pr1 Minimum time load on 0 ÷ 99.5 (min.1sec)
CP14
0 nu nu Pr1 Maximum time load on (0=nu) 0 ÷ 24 (h) – with 0 the function is disabled
CP15
0 0 0 Pr1 Min time Frq1-2 off after CP14 0 ÷ 255 (min)
CP16
no NO NO Pr1 CP11 enabled also at first on no - YES
CP17
no NO NO Pr1 CP12 enabled also at first off no - YES
CP18
10 10 10 Pr1 Output delay at power on 0 ÷ 255 (sec)
CP19
- NO NO Pr2 Booster function enabled no - YES
F1
4,0 4.0 4.0 Pr1 Regulation band width circuit 1
(BAR)
0.10÷10.00
(°C)
0.0÷30.0
(PSI)
1÷80
(°F)
1÷50.0
F2
10,0 10.0 10.0 Pr1 Minimum set point circuit 1 BAR: (AI9 ÷SETF1); °C: (-50.0 ÷ SETF1);
PSI : (AI9 ÷ SETF1); °F : (-58.0 ÷ SETF1)
F3
60,0 60.0 60.0 Pr1 Maximum set point circuit 1 BAR: (SETF1÷AI10); °C : (SETF1 ÷ 150.0);
PSI : (SETF1 ÷ AI10); °F: (SETF1 ÷ 302)
F4
0,0 0.0 0.0 Pr1 Energy saving circuit 1
(BAR)
-20.00÷20.00
(°C)
-50.0÷50.0
(PSI)
-
300÷300
(°F)
-90÷90
F5
- 4.0 4.0 Pr1 Regulation band width circuit 2
(BAR)
0.10÷10.00
(°C)
0.0÷30.0
(PSI)
1÷80
(°F)
1÷50.0
F6
- 10.0 10.0 Pr1 Minimum set point circuit 2 BAR: (AI12 ÷ SETF2); °C: (-50.0 ÷ SETF2);
PSI : (AI12 ÷ SETF2); °F : (-58.0 ÷ SETF2)
F7
- 60.0 60.0 Pr1 Maximum set point circuit 2 BAR: (SETF2÷AI13); °C : (SETF2 ÷ 150.0);
PSI : (SETF2 ÷ AI13); °F: (SETF2 ÷ 302)
F8
- 0.0 0.0 Pr1 Energy saving circuit 2
(BAR)
-20.00÷20.00
(°C)
-50.0÷50.0
(PSI)
-
300÷300
(°F)
-90÷90
F9
15 15 15 Pr1 2 different fan start delay 1 ÷ 255 (sec)
F10
5 5 5 Pr1 2 different fan off delay 1 ÷ 255 (sec)
HS1
nu nu nu Pr1 Energy Saving start time on Monday 0:0÷23.5h; nu
HS2
00,00 00:00 00:00 Pr1 Monday Energy Saving duration 0:0÷23.5h;
HS3
nu nu nu Pr1 Energy Saving start time on Tuesday 0:0÷23.5h; nu
HS4
00,00 00:00 00:00 Pr1 Tuesday Energy Saving duration 0:0÷23.5h;
HS5
nu nu nu Pr1 Energy Saving start time on
Wednesday
0:0÷23.5h; nu
HS6
00,00 00:00 00:00 Pr1 Wednesday Energy Saving duration 0:0÷23.5h;
HS7
nu nu nu Pr1 Energy Saving start time on Thursday 0:0÷23.5h; nu
HS8
00,00 00:00 00:00 Pr1 Thursday Energy Saving duration 0:0÷23.5h;
HS9
nu nu nu Pr1 Energy Saving start time on Friday 0:0÷23.5h; nu
HS10
00,00 00:00 00:00 Pr1 Friday Energy Saving duration 0:0÷23.5h;
HS11
nu nu nu Pr1 Energy Saving start time on Saturday 0:0÷23.5h; nu
HS12
00,00 00:00 00:00 Pr1 Saturday Energy Saving duration 0:0÷23.5h;
