Nome XC
1008
D
XC
1011
D
XC
1015
D
Level
Description Range
HS13
nu nu nu Pr1 Energy Saving start time on Sunday 0:0÷23.5h; nu
HS14
00,00 00:00 00:00 Pr1 Sunday Energy Saving duration 0:0÷23.5h;
AC1
30 30 30 Pr1 Probe 1 alarm delay at power on 0 ÷ 255 (min)
AC2
- 30 30 Pr1 Probe 2 alarm delay at power on 0 ÷ 255 (min)
AC3
15,0 15.0 15.0 Pr1 Minimum temp/press alarm circuit 1 (0.10 ÷ 30.00)
BAR
(0.0 ÷ 100.0)
°C
(1 ÷ 430)
PSI
(1 ÷ 200.0)
°F
AC4
20,0 20.0 20.0 Pr1 Maximum temp/press alarm circuit 1 (0.10 ÷ 30.00)
BAR
(0.0 ÷ 100.0)
°C
(1 ÷ 430)
PSI
(1 ÷ 200.0)
°F
AC5
20 20 20 Pr1 Temp/press alarm delay circuit 1 0 ÷ 255 (min)
AC6
- 15.0 15.0 Pr1 Minimum temp/press alarm circuit 2 (0.10 ÷ 30.00)
BAR
(0.0 ÷ 100.0)
°C
(1 ÷ 430)
PSI
(1 ÷ 200.0)
°F
AC7
- 20.0 20.0 Pr1 Maximum temp/press alarm circuit 2 (0.10 ÷ 30.00)
BAR
(0.0 ÷ 100.0)
°C
(1 ÷ 430)
PSI
(1 ÷ 200.0)
°F
AC8
- 20 20 Pr1 Temp/press alarm delay circuit 2 0 ÷ 255 (min)
AC9
ALr ALr ALr Pr1 Relay for temp/press alarm nu - ALr - ALr1 - ALr2
AC10
20000 20000 20000 Pr1 Running hours for maintenance 0 ÷ 25000 – with 0 the function is disabled
AC11
ALr ALr ALr Pr1 Relay for maintenance alarm nu - ALr - ALr1 - ALr2
AC12
15 15 15 Pr1 LP switch 1 activation number 0 ÷ 15
AC13
15 15 15 Pr1 LP switch 1 activation time 0 ÷ 255 (min)
AC14
2 2 2 Pr1 Compressure on-faulty probe1 0 ÷ 15
AC16
- 15 15 Pr1 LP switch 2 activation number 0 ÷ 15
AC17
- 15 15 Pr1 LP switch 2 activation time 0 ÷ 255 (min)
AC18
- 2 2 Pr1 Compressure on-faulty probe2 0 ÷ 15
AF1
20,0 20.0 20.0 Pr1 Minimum temp/press alarm circuit 1 (0.10 ÷ 30.00)
BAR
(0.0 ÷ 100.0)
°C
(1 ÷ 430)
PSI
(1 ÷ 200.0)
°F
AF2
20,0 20.0 20.0 Pr1 Maximum temp/press alarm circuit 1 (0.10 ÷ 30.00)
BAR
(0.0 ÷ 100.0)
°C
(1 ÷ 430)
PSI
(1 ÷ 200.0)
°F
AF3
20 20 20 Pr1 Temp/press alarm delay circuit 1 0 ÷ 255 (min)
AF4
no NO NO Pr1 Compressor off with max alarm 1 no - YES
AF5
2 2 2 Pr1 Off delay with max alarm 1 0 ÷ 255 (min)
AF6
15 15 15 Pr1 HP switch 1 activation number 0 ÷15
AF7
15 15 15 Pr1 HP switch 1 activation time 0 ÷ 255 (min)
AF8
2 2 2 Pr1 Fans on with faulty probe 3 0 ÷ 15
AF9
- 20.0 20.0 Pr1 Minimum temp/press alarm circuit 2 (0.10 ÷ 30.00)
BAR
(0.0 ÷ 100.0)
°C
(1 ÷ 430)
PSI
(1 ÷ 200.0)
°F
AF10
- 20.0 20.0 Pr1 Maximum temp/press alarm circuit 2 (0.10 ÷ 30.00)
BAR
(0.0 ÷ 100.0)
°C
(1 ÷ 430)
PSI
(1 ÷ 200.0)
°F
AF11
- 20 20 Pr1 Temp/press alarm delay circuit 2 0 ÷ 255 (min)
AF12
- NO NO Pr1 Compressor off with max alarm 2 no - YES
AF13
- 2 2 Pr1 Off delay with max alarm 2 0 ÷ 255 (min)
AF14
- 15 15 Pr1 HP switch 2 activation number 0 ÷15
AF15
- 15 15 Pr1 HP switch 2 activation time 0 ÷ 255 (min)
AF16
- 2 2 Pr1 Fans on with faulty probe 3 0 ÷ 15
AF17
ALr ALr ALr Pr1 Relay for temp/press alarm nu - ALr - ALr1 - ALr2
O1
no NO NO Pr2 Dynamic set enabled - circuit 1 no - YES
O2
-18,0 -18.0 -18.0 Pr2 Maximum set for circuit 1 SETC1÷CP3
O3
15,0 15.0 15.0 Pr2 Dynamic set start temperature circuit 1 -40÷O4 °C /-40÷O4°F
O4
15,0 15.0 15.0 Pr2 Dynamic set stop temperature circuit 1 O3÷150°C /O3÷302°F
O5
- NO NO Pr2 Dynamic set enabled - circuit 2 no - YES
O6
- -18.0 -18.0 Pr2 Maximum set for circuit 2 SETC2÷CP7
O7
- 15.0 15.0 Pr2 Dynamic set start temperature circuit 2 -40÷O8°C /-40÷O8°F
O8
- 15.0 15.0 Pr2 Dynamic set stop temperature circuit 2 O7÷150°C /O7÷302°F
O9
no NO NO Pr2 Dynamic set enabled - circuit 1 no - YES
O10
25,0 25.0 25.0 Pr2 Minimum condens. set - circuit 1 F2÷SETF1
O11
15 15.0 15.0 Pr2 Differential dynamic set-circuit 1 (BAR) -20.00÷20.00 (°C) -50.0÷50.0 (PSI) -
