Nome XC
1008
D
XC
1011
D
XC
1015
D
Level
Description Range
300÷300 (°F) -90÷90
O12
- NO NO Pr2 Dynamic set enabled - circuit 2 no - YES
O13
- 25.0 25.0 Pr2 Minimum condens. set - circuit 2 F6÷SETF2
O14
- 15.0 15.0 Pr2 Differential dynamic set-circuit 2 (BAR) -20.00÷20.00 (°C) -50.0÷50.0 (PSI) -
300÷300 (°F) -90÷90
1Q1
4.20mA
4.20mA
4.20mA
Pr1 Analog outputs 1-2 setting 4.20 mA (0) - 0.10 V (1)
1Q2
nu nu nu Pr1 Analog output 1 function FREE – CPR - CPR2 - FAN - FAN2 - INVF1 -
INVF2 - nu
1Q3
Pbc1 Pbc1 Pbc1 Pr1 Probe for analog output 1 Pbc1(0) - Pbc2(1) ; used only with 1Q2 = 0
1Q4
0.0 0.0 0.0 Pr1 Lower limit for analog output 1 -1÷100.00 bar; -15÷750PSI; -50÷150°C; -
58÷302°F;
1Q5
100.0 100.0 100.0 Pr1 Upper limit for analog output 1 -1÷100.00 bar; -15÷750PSI; -50÷150°C; -
58÷302°F;
1Q6
30 50 50 Pr1 Minimum value for analog output 1 0 ÷ 100 %
1Q7
40 50 50 Pr1 Analog output 1 value after compressor
start
1Q6 ÷ 100 %
1Q8
40 60 60 Pr1 Analog output 1 value after compressor
off
1Q6 ÷ 100 %
1Q9
40 50 50 Pr1 Exclusion band start value 1 1Q7 ÷ 100 %
1Q10
40 50 50 Pr1 Exclusion band end value 1 1Q9 ÷ 100 %
1Q11
50 50 50 Pr1 Safety value for Analog output 1 0 ÷ 100 (%)
1Q12
0 0 0 Pr1 Regulation delay after exit from neutral
zone
0 ÷ 255 (sec)
1Q13
60 60 60 Pr1 Analog output 1 rise time 0 ÷ 255 (sec)
1Q14
10 10 10 Pr1 Analog output 1 permanency before
load activation
0 ÷ 255 (sec)
1Q15
0 2 2 Pr1 Analog output 1 decreasing delay 0 ÷ 255 (sec)
1Q16
150 5 5 Pr1 Analog output 1 decreasing time 0 ÷ 255 (sec)
1Q17
10 5 5 Pr1 Analog output 1 permanency before
load off
0 ÷ 255 (sec)
1Q18
5 5 5 Pr1 Analog output 1 decreasing time after
load off
0 ÷ 255 (sec)
1Q19
4.0 4.0 4.0 Pr1 Regulation band width 1 0.10÷25.00bar; 0.0÷25.0°C; 1÷250 PSI;
1÷250°F;10÷2500 KPA
1Q20
350 350 350 Pr1 Integral time 1 0÷999s; with 0 integral action excluded
1Q21
0.0 0.0 0.0 Pr1 Band offset 1 (-12.0÷12.0°C -12.00 ÷ 12.00BAR, -
120÷120°F, -120÷120PSI; -1200÷1200KPA
1Q22
4.0 4.0 4.0 Pr1 Anti reset wind-up 1 0.0÷99.0 °C; 0÷180°F; 0.00÷50,00bar;
0÷725PSI; 0÷5000kPA
1Q24
0 0 0 Pr1 Minimum capacity of inverter 1 0÷99%; with 0 function excluded
1Q25
255 255 255 Pr1 Maximum time at minimum capacity of
inverter 1
1÷255min
1Q26
2 2 2 Pr1 Time at maximum capacity of inverter 1
1÷255min
2Q1
- nu nu Pr1 Analog output 2 function FREE – CPR - CPR2 - FAN - FAN2 - INVF1 -
INVF2 - nu
2Q2
- Pbc2 Pbc2 Pr1 Probe for analog output 2 Pbc1(0) - Pbc2(1) ; usata solo quando 2Q2 = 0
2Q3
- 0.0 0.0 Pr1 Lower limit for analog output 2 -1÷100.00 bar; -15÷750PSI; -50÷150°C; -
58÷302°F;
2Q4
- 100.0 100.0 Pr1 Upper limit for analog output 2 -1÷100.00 bar; -15÷750PSI; -50÷150°C; -
58÷302°F;
2Q5
- 50 50 Pr1 Minimum value for analog output 2 0 ÷ 100 (%)
2Q6
- 50 50 Pr1 Analog output 2 value after compressor
start
2Q5 ÷ 100 %
2Q7
- 60 60 Pr1 Analog output 2 value after compressor
off
2Q5 ÷ 100 %
2Q8
- 50 50 Pr1 Exclusion band start value 2 2Q6 ÷ 100 %
2Q9
- 50 50 Pr1 Exclusion band end value 2 2Q8 ÷ 100 %
