Nome XC
1008
D
XC
1011
D
XC
1015
D
Level
Description Range
2Q10
- 50 50 Pr1 Safety value for Analog output 2 0 ÷ 100 (%)
2Q11
- 0 0 Pr1 Regulation delay after exit from neutral
zone
0 ÷ 255 (sec)
2Q12
- 60 60 Pr1 Analog output 2 rise time 0 ÷ 255 (sec)
2Q13
- 10 10 Pr1 Analog output 2 permanency before
load activation
0 ÷ 255 (sec)
2Q14
- 2 2 Pr1 Analog output 2 decreasing delay 0 ÷ 255 (sec)
2Q15
- 5 5 Pr1 Analog output 2 decreasing time 0 ÷ 255 (sec)
2Q16
- 5 5 Pr1 Analog output 2 permanency before
load off
0 ÷ 255 (sec)
2Q17
- 5 5 Pr1 Analog output 2 decreasing time after
load off
0 ÷ 255 (sec)
2Q18
- 4.0 4.0 Pr1 Regulation band width 2 0.10÷25.00bar; 0.0÷25.0°C; 1÷250 PSI;
1÷250°F;10÷2500 KPA
2Q19
- 350 350 Pr1 Integral time 2 0÷999s; with 0 integral action excluded
2Q20
- 0.0 0.0 Pr1 Band offset 2 -12.0÷12.0°C -12.00 ÷ 12.00BAR, -
120÷120°F, -120÷120PSI; -1200÷1200KPA
2Q21
- 4.0 4.0 Pr1 Anti reset wind-up 2 0.0÷99.0 °C; 0÷180°F; 0.00÷50,00bar;
0÷725PSI; 0÷5000kPA
2Q23
- 0 0 Pr1 Minimum capacity of inverter 2 0÷99%; with 0 function excluded
2Q24
- 255 255 Pr1 Maximum time at minimum capacity of
inverter 2
1÷255min
2Q25
- 2 2 Pr1 Time at maximum capacity of inverter 2
1÷255min
3Q1
4.20mA
4.20mA
4.20mA
Pr1 Analog outputs 3-4 setting 4.20 mA (0) - 0.10 V (1)
3Q2
nu nu nu Pr1 Analog output 3 function FREE – CPR - CPR2 - FAN - FAN2 - INVF1 -
INVF2 - nu
3Q3
Pbc3 Pbc3 Pbc3 Pr1 Probe for analog output 3 Pbc3(0); Pbc4(1); used with 3Q2 = 0
3Q4
0.0 0.0 0.0 Pr1 Lower limit for analog output 3 -1÷100.00 bar; -15÷750PSI; -50÷150°C; -
58÷302°F;
3Q5
100.0 100.0 100.0 Pr1 Upper limit for analog output 3 -1÷100.00 bar; -15÷750PSI; -50÷150°C; -
58÷302°F;
3Q6
30 50 50 Pr1 Minimum value for analog output 3 0 ÷ 100 (%)
3Q7
40 50 50 Pr1 Analog output 3 value after fan start 3Q6 ÷ 100 %
3Q8
40 70 70 Pr1 Analog output 3 value after fan off 3Q6 ÷ 100 %
3Q9
40 50 50 Pr1 Exclusion band start value 3 3Q7 ÷ 100 %
3Q10
40 50 50 Pr1 Exclusion band end value 3 3Q9 ÷ 100 %
3Q11
50 50 50 Pr1 Safety value for Analog output 3 0 ÷ 100 (%)
3Q12
0 0 0 Pr1 Regulation delay after exit from neutral
zone
0 ÷ 255 (sec)
3Q13
60 60 60 Pr1 Analog output 3 rise time 0 ÷ 255 (sec)
3Q14
10 10 10 Pr1 Analog output 3 permanency before
load activation
0 ÷ 255 (sec)
3Q15
0 0 0 Pr1 Analog output 3 decreasing delay 0 ÷ 255 (sec)
3Q16
150 15 15 Pr1 Analog output 3 decreasing time 0 ÷ 255 (sec)
3Q17
10 5 5 Pr1 Analog output 3 permanency before
load off
0 ÷ 255 (sec)
3Q18
5 5 5 Pr1 Analog output 3 decreasing time after
load off
0 ÷ 255 (sec)
3Q19
4.0 4.0 4.0 Pr1 Regulation band width 3 0.10÷25.00bar; 0.0÷25.0°C; 1÷250 PSI;
1÷250°F;10÷2500 KPA
3Q20
500 500 500 Pr1 Integral time 3 0÷999s; with 0 integral action excluded
3Q21
0.0 0.0 0.0 Pr1 Band offset 3 (-12.0÷12.0°C -12.00 ÷ 12.00BAR, -
120÷120°F, -120÷120PSI; -1200÷1200KPA
3Q22
4.0 4.0 4.0 Pr1 Anti reset wind-up 3 0.0÷99.0 °C; 0÷180°F; 0.00÷50,00bar;
0÷725PSI; 0÷5000kPA
3Q24
0 0 0 Pr1 Minimum capacity of inverter 3 0÷99%; with 0 function excluded
