Nome XC
1008
D
XC
1011
D
XC
1015
D
Level
Description Range
3Q25
255 255 255 Pr1 Maximum time at minimum capacity of
inverter 3
1÷255min
3Q26
2 2 2 Pr1 Time at maximum capacity of inverter 3
1÷255min
4Q1
- nu nu Pr1 Analog output 4 function FREE – CPR - CPR2 - FAN - FAN2 - INVF1 -
INVF2 - nu
4Q2
- Pbc4 Pbc4 Pr1 Probe for analog output 4 Pbc3(0); Pbc4(1); used with 4Q1 = 0
4Q3
- 0.0 0.0 Pr1 Lower limit for analog output 4 -1÷100.00 bar; -15÷750PSI; -50÷150°C; -
58÷302°F;
4Q4
- 100.0 100.0 Pr1 Upper limit for analog output 4 -1÷100.00 bar; -15÷750PSI; -50÷150°C; -
58÷302°F;
4Q5
- 50 50 Pr1 Minimum value for analog output 4 0 ÷ 100 (%)
4Q6
- 50 50 Pr1 Analog output 4 value after fan start 4Q5÷ 100 %
4Q7
- 70 70 Pr1 Analog output 4 value after fan off 4Q5÷ 100 %
4Q8
- 50 50 Pr1 Exclusion band start value 4 4Q6 ÷ 100 %
4Q9
- 50 50 Pr1 Exclusion band end value 4 4Q8 ÷ 100 %
4Q10
- 50 50 Pr1 Safety value for Analog output 4 0 ÷ 100 (%)
4Q11
- 0 0 Pr1 Regulation delay after neutral zone exit 0 ÷ 255 (sec)
4Q12
- 60 60 Pr1 Analog output 4 rise time 0 ÷ 255 (sec)
4Q13
- 10 10 Pr1 Analog output 4 permanency before
load activation
0 ÷ 255 (sec)
4Q14
- 0 0 Pr1 Analog output 4 decreasing delay 0 ÷ 255 (sec)
4Q15
- 15 15 Pr1 Analog output 4 decreasing time 0 ÷ 255 (sec)
4Q16
- 5 5 Pr1 Analog output 4 perm before load off 0 ÷ 255 (sec)
4Q17
- 5 5 Pr1 Analog output 4 decreasing time after
load off
0 ÷ 255 (sec)
4Q18
- 4.0 4.0 Pr1 Regulation band width 4 0.10÷25.00bar; 0.0÷25.0°C; 1÷250 PSI;
1÷250°F;10÷2500 KPA
4Q19
- 500 500 Pr1 Integral time 4 0÷999s; with 0 integral action excluded
4Q20
- 0.0 0.0 Pr1 Band offset 4 (-12.0÷12.0°C -12.00 ÷ 12.00BAR, -
120÷120°F, -120÷120PSI; -1200÷1200KPA
4Q21
- 4.0 4.0 Pr1 Anti reset wind-up 4 0.0÷99.0 °C; 0÷180°F; 0.00÷50,00bar;
0÷725PSI; 0÷5000kPA
4Q23
- 0 0 Pr1 Minimum capacity of inverter 4 0÷99%; with 0 function excluded
4Q24
- 255 255 Pr1 Maximum time at minimum capacity of
inverter 4
1÷255min
4Q25
2 2 Pr1 Time at maximum capacity of inverter 4
1÷255min
AR1
0,0 0,0 0,0 0,0 Set point aux relay 1 -40÷110°C/-40÷230°F
AR2
1,0 1,0 1,0 1,0 Differential for aux relay 1 0,1÷25,0°C/1÷50°F
AR3
CL CL CL CL Kind of aciton for aux 1 CL = cooling; Ht = heating
AR4
0,0 0,0 0,0 0,0 Set point aux relay 2 -40÷110°C/-40÷230°F
AR5
1,0 1,0 1,0 1,0 Differential for aux relay 2 0,1÷25,0°C/1÷50°F
AR6
CL CL CL CL Kind of aciton for aux 2 CL = cooling; Ht = heating
AR7
0,0 0,0 0,0 0,0 Set point aux relay 3 -40÷110°C/-40÷230°F
AR8
1,0 1,0 1,0 1,0 Differential for aux relay 3 0,1÷25,0°C/1÷50°F
AR9
CL CL CL CL Kind of aciton for aux 3 CL = cooling; Ht = heating
AR10
0,0 0,0 0,0 0,0 Set point aux relay 4 -40÷110°C/-40÷230°F
AR11
1,0 1,0 1,0 1,0 Differential for aux relay 4 0,1÷25,0°C/1÷50°F
AR12
CL CL CL CL Kind of aciton for aux 4 CL = cooling; Ht = heating
OT1
yES yES yES yES Alarm relay off by keyboard no - YES
OT2
CL CL CL CL Alarm relay polarity OP - CL
OT3
yES yES yES yES Alarm relay 1 off by keyboard no - YES
OT4
OP OP OP OP Alarm relay 1 polarity OP - CL
OT5
yES yES yES yES Alarm relay 2 off by keyboard no - YES
OT6
OP OP OP OP Alarm relay 2 polarity OP - CL
OT7
1 1 1 1 Serial address 1 ÷ 247
