XWEB PRO 10/23
ATTENTION: the status of the System LED is linked to that of the corresponding "System alarm" relay
ATTENTION: for XWEB300D the 'relay system' as AUX assumes the following logic:
• at rest (XWEB off) contacts 30 and 32 are closed
• in the event of an alarm, it closes at 30-31
• when switched on, it closes for a few seconds at 30-31. then if there are no alarms it returns to rest and
closes at 30-32.
ATTENTION: always use the power supply of the external modem from the XWEB itself to ensure the
correct sending of messages (for example SMS). In other words, use the cable supplied in the modem KIT
on terminals 33-34.
ATTENTION: the 'reset modem' relay is energized for reset, in conditions of non-use every two minutes; and
before each activation of the service. It is necessary to insert this relay in the power supply circuit of the
external modem to ensure the correct sending of messages (SMS).
ATTENTION: During the initial start-up phase, the STATUS, REC and ALARM LEDs FLASH at regular
intervals. This flashing IS NORMAL and highlights the regular progress of the ignition phase which can last
up to 5 minutes.
• Avoid direct passage between operators as much as possible (to avoid electrostatic
induction and subsequent discharges);
• If the electrical voltage supply differs from the required rating, this could seriously damage
the system;
• Connection errors (and connections that differ from the prescribed ones) can pose a danger
to operator safety and cause faults in the system and to the instruments that are connected
to it;
• Insert one or more easily accessible disconnecting devices to the exterior of the device to
separate the device from the power mains;
• Do not use the device in environments with flammable gases.
• Do not modify the device in any way.
