Emerson XWEB300D Installation

XWEB PRO 7/23
4. DANE TECHNICZNE
Wymiary
175 x 110 x 41 mm
Mocowanie
Urządzenie montowane na szynie DIN
Stopień ochrony
Do użytku w pomieszczeniach, Typ otwarty (NEMA - UL 50e)
IP20 (EN60529)
Źródło zasilania
100-240VAC ±10%
Częstotliwość źródła
zasilania
50/60 Hz
Kategoria przepięciowa
II
Moc znamionowa
15VA Max
Znamionowe napięcie
impulsowe
2500V
Prąd znamionowy
bezpiecznika
15A
Rodzaj zadziałania
1.B
Stopień zanieczyszczenia
2
Temperatura otoczenia
podczas pracy
-20 - 60°C
Temperatura do transportu
oraz magazynowania
-40 - 85°C
Field wiring terminal
identification, wire size and
torque value
Rodzaj zacisków przewodów
i wartość momentu
obrotowego
The serial line cable can be of the two-wire type plus the shield, with a
minimum section of 0.5mm2 (eg BELDEN 8772).
Internal battery and RTC
accuracy
Rechargeable and non-removable lithium battery. 50ppm for temperature
variation up to 60 ° C, 5ppm for aging. The maximum drift of the clock in a
year is therefore 33 min per year
Digital Inputs
Optoisolated with common at + 12Vdc (isolated), connectable via 2-way
terminal block. Present only for XWEB500D
Digital Outputs
AUX1-2-3 clean contacts for 24/120 / 240Vac max 5A resistive loads.
AUX1 port ("Systema Alarm") in exchange; connectable via 3-way
terminal block; always present. AUX2 ('Alarm 1') and AUX3 ('Alarm 2')
ports that can be connected via a 2-way terminal block; present only for
XWEB500D.
"Pwr Ext Modem" clean contacts 12Vdc max 250mA connectable via 2-
way terminal block; always present
RS485 Ports
RS485 port 1: optically isolated (always present)
RS485 port 2: optically isolated (only for XWEB500D)
USB Ports
1 standard HOST connector type A port
Maximum deliverable current 500 mA
Purpose of control
Operating control
Construction of control
Independently mounted control
Approvals
CE, UL. The system consisting of this control and monitoring unit and
Dixell temperature meters compliant with the EN13485 standard complies
with the EC regulation no. 37/2005 and in particular with the EN12830
standard. Temperature recorders for the transport and storage and
distribution of chilled, frozen, deep-frozen and ice-cream products (UNI
EN 12830, S, A, 1, measurement range corresponding to the class of
connected devices)
CAUTION
The terminal board for connecting the relays can be used to directly drive
high voltage loads (higher than 24V) but the voltages between the different
terminals cannot be mixed.
