Page 103
1.5.5 Cooling funct.
04. 07. 2015 10:43
Hyst.tank 1
Hyst.tank 2
t-ON
t OFF
Adjusting balance
2.0K
2.0K
00:00
07:00
1.5.6 Soft charge
04. 07. 2015 10:43
Activation
T min. tank1
T min. tank2
Start
End
45.0°C
45.0°C
30.05.
31.07.
PROFESSIONAL MODE
Soft charging sets the plant to
protection mode to prevent
excessively high tank temperatures.
The start temperatures for two
tank circuits and the appropriate
calendar period are determined here.
Return to ›Main menu‹.
Continue with ›Monitoring‹.
If the adjusting balance is activated, the
heat dissipated via the collector is deducted
from the energy balance calculation.
Continue with ›Soft charge‹.
Note!
To protect the pump, the collector emergency switch-off in
solar circuits with high-efciency pumps is reduced to 100°C.
Soft charge is not possible at higher temperatures!
