Page 54
0.7.2 Holiday function
04. 07. 2015 09:26
Tank recooling
Soft charge
T-ON
T-OFF
Next
113.0°C
100.0°C
Test outputs
Holiday function
Next
0.7 Checklist
04. 07. 2015 09:26
Various options can be selected
for the holiday function.
At lower ambient temperatures
(e. g. at night), tank recooling tries
to dissipate heat via the collectors.
The soft charge circuit is designed so that the
heat input into the tank is as low as possible.
The appropriate switch-ON and OFF
temperatures must be varied as required.
Acknowledge by pressing ›Next‹.
Select the „Holiday function“.
COMMISSIONING MODE
Note!
If the hydraulic installation does not comply with the standard, or if
special products were used which cause incorrect valve positions during
test operation, the „Inverted“ option must be activated by accessing the
corresponding output menu 1.3.7 in professional mode after commis-
sioning. The controller will then exchange energized and de-energized
conditions.
