Ender 3 Series - 1. Introduction to Ender 3 Printer

1. Introduction
1
1. Control Box
2. TF Slot and USB Port
3. Print Surface
4. Control Knob
5. Display
6. Nozzle Assembly
7. Spool Holder
8. Extruder (E) Stepper
9. Power
10. Y Limit Switch
11. Y Stepper
12. Coupling
13. Z Stepper
14. Z Limit Switch
15. X Limit Switch
16. X Stepper
6
5
21
4
3
16
15
7
8
14
9
13
10
11
12
