Installation
Hardware Installation and Maintenance Manual 3
–3
Mounting and Installing the Analyzer
Installing the analyzer is relatively easy requiring only a few steps that, when
carefully followed, will ensure proper mounting and connection. The steps are
outlined in the following sections:
• Hardware and tools for mounting and installation
• To mount the analyzer
• Connecting Electrical Power to the Analyzer
• Connecting the Output Signals and Alarms
• Ethernet connection (Optional)
Hardware and tools for mounting and installation
Depending on the particular configuration of accessories and options ordered,
you may need the following hardware and tools to complete the installation
process.
Hardware
• Mounting hardware (e.g., 3/8 in. x 1-1/2 in. machine screws and
nuts)
• Stainless steel tubing (SpectraSensors recommends using 1/4 in.
O.D. x 0.035 in. wall thickness, seamless stainless steel tubing)
• 3/4 in. conduit
• 3/4 in. conduit hubs
Tools
• Hand drill and bits
• Tape measure
• Level
• Pencil
• 9/16 in. socket wrench
• Screw driver
• 9/16 in. open-end wrench
Mounting hardware used for wall-mounting the 2-Pack must be
able to support four times the weight of the instrument
(approximately 86 Kg [190 lbs]).
