Endress+Hauser SpectraSensors SS500 Hardware Installation And Maintenance Manual

2-Pack Analyzer System
A–4 4900002256 rev. B 4-13-21
1. Application dependent.
Table A-2 2-Pack: Analyzer A (H
2
S) / Analyzer B (H
2
O) specifications (Continued)
Electrical & Communications (Continued)
Communication
Analog Output: (4) Isolated 4-20 mA,
1200 ohms at 24 VDC maximum (concentration
only)
Serial Analyzer A (H
2
S): RS-232
(all parameters) and Ethernet
Serial Analyzer B (H
2
O): RS-232
(all parameters) or optional Ethernet
Protocol: Modbus Gould RTU or Daniel RTU
Digital Outputs
Analyzer A (H
2
S): Concentration Alarm,
General Fault, Validation Fail
1
, Validation 1
Active
1
, Validation 2 Active
1
Analyzer B (H
2
O): General Fault and (1) Hi/Lo
Concentration Alarm
Physical Specifications
Size (typical)
1283 mm H  762 mm W  386 mm D
(50 1/2 in. H  30 in. W  15 3/16 in. D)
Weight (typical) Approximately 86 Kg (190 lbs)
Sample Cell Construction 316L series polished stainless steel
Area Classification
Analyzer with Sample
Conditioning System
Class I, Division 2, Grp. B, C and D, T3/T3C IP66
Class I, Zone 2 IIB+H2 T3/T3C IP66
For a complete listing of new or updated certificates and manuals,
please visit the product page at www.spectrasensors.com.
Configurations requiring optional accessories (e.g., probe
assemblies) with specific characteristics must meet manufacturer
specifications.
