NOTE: The infrared sensor on the DVR is just to the right of the camera buttons.
Make certain that nothing blocks the sensor, or the remote control will not function
properly.
When you use wireless communication devices (such as Wi-Fi or Bluetooth) near
the DVR, the remote control might not function properly.
You can also use a USB mouse (not supplied) to navigate through the screens and
menus much like you would on a computer.
Camera Buttons Pressing the individual camera buttons will cause the selected
camera to display full screen. Buttons 1 to 9 are also used
to enter passwords. In the PTZ mode, pressing the button 1
zooms in the screen and the button 2 zooms out the screen,
pressing the button 3 focuses near and button 4 focuses far,
and pressing the button 5 moves to the preset and button 6
saves the preset.
HDD LED The HDD LED flickers when the DVR is recording or searching
video on the hard disk drive.
Alarm Out LED The Alarm Out LED is lit when alarm output or internal buzzer is
activated.
Network LED The Network LED is lit when the unit is connected to a network
via Ethernet.
Clip Copy LED The Clip Copy LED is lit when the DVR is clip-copying.
Power LED The Power LED is lit when the unit is On.
PANIC Button Pressing the PANIC button starts panic recoding of all camera
channels, and displays
on the screen. Pressing the button
again will stop panic recording.
ALARM Button The ALARM button has two functions. First, it will reset the
DVR’s outputs including the internal buzzer during an alarm.
Second, it will display the event log when you are in the live
monitoring mode unless there is an active alarm. This operation
can be user password protected.
CLIP COPY
Button
Pressing the CLIP COPY button allows you to copy video clips.
