4 Installation
Rating plate content:
Year of manufacture
Designation
Serial number
Type
Weight
Lifting hook, max
Max hydraulic pressure
966792
Figure 3.
4.2. Mechanical
The following mounting and installation instructions assume the
excavator to be equipped with the appropriate locking hydraulics. If the
base machine does not have locking hydraulics, contact engcon for
reference to the recommended installation kit.
DANGER
Do not exceed tipping load limits.
The weight of the product and the
increased reach may impair stability.
Risk of personal injury and damage to
property.
WARNING
If you have any doubts concerning
the safety aspects of your knowledge,
the equipment or work, contact a
dealer or engcon Nordic AB. Incorrect
installation affect safety.
IMPORTANT
Assembly and installation may only be
carried out at a workshop authorized by the
manufacturer. Changes to the assembly may
not be carried out without the manufacturer’s
consent.
