10 Glossary
10. Glossary
10.1. Designations
Term
Description
Base machine
The machine carrying the equipment concerned. Excavator or backhoe loader.
EC-Oil
Automatic oil connection system for changing hydraulic tools from the cab. See section
3.3. EC-Oil.
EC-Oil block H
(coupler)
Located in the machine or in the quick coupler.
EC-Oil block T (Top)
Located on the upper section of the hydraulic tool and/or the tiltrotator.
Dog bone linkage
The link between the breakout cylinder and the machine coupler or directly attached
tiltrotator.
Machine coupler
Quick coupler mounted directly on the excavator's stick
Stick
The 'arm' at the very front of the excavator.
Tipping load
Specifies the maximum weight the excavator is able to lift without tipping forward.
10.2. Abbreviations
Term
Description
QLM
Warning light and sound that alerts if the bucket or other tool is incorrectly connected.
QSC
engcon's standardized locking system for controlling all types of machine couplers and
quick couplers.
