4 Installation
For EC-Oil QS45-60 (SS9)
Fit the hydraulic hoses as shown in Figure 11.
Close (C)
Open (O)
Pressure B (Pb)
Pressure A (Pa)
Rotation A (Ra)
Rotation B (Rb)
2167699
Figure 11. Bildtext
Central lubrication
For EC-Oil QS70-80 (DC2, SS10)
Fit the hydraulic hoses as shown in Figure 12.
Close (C)
Open (O)
Tank (T)
Pressure (P)
2167035
Figure 12. Osynlig texten
Central lubrication
For EC-Oil QS70-80 (SS9)
Fit the hydraulic hoses as shown in Figure 13.
Close (C)
Open (O)
Pressure B (Pb)
Pressure A (Pa)
Rotation A (Ra)
Rotation B (Rb)
2167712
Figure 13. Osynligt bildtext
Central lubrication
4.5. Q-Safe
See separate installation instructions.
Also available on the website or by contacting engcon.
