5 Operation
5.2. Lifting points
Check max permitted load for the lifting hook, as stamped on the lifting
hook and rating plate. Designed with safety factor 5:1.
WARNING
The base machine must be equipped
with a load-holding valve on the
boom/stick and an overload warning
when using a lifting hook on the
machine coupler. Risk of personal
injury and damage to property.
5.3. Changing tools
The following instructions concern general operation of engcon machine couplers.
5.3.1. Connecting the tool, hydraulic lock
1. Activate the quick coupler lock function.
2. Activate the hydraulics to operate the locking bolts.
26
