IQ Gateway Operation
IQ Gateway Displays and Controls
You can track system installation progress with the Enphase Installer App mobile app.
The LEDs on the IQ Gateway are solid green when a function is enabled or performing as expected,
flashing when an operation is in progress, or solid amber when troubleshooting with Installer App is
required.
—
Network Communications LED: Green when IQ Gateway is connected to Enphase Installer
App.
—
AP Mode LED: Green when IQ Gateway’s AP Wi-Fi network is available.
—
AP Mode Button: Press to enable IQ Gateway’s AP Mode for connecting with
a mobile device. Hold for 5 seconds to start WPS connection to a router.
—
Power Production LED: Green when microinverters are producing power.
—
Device Communications LED: Green when microinverters are communicating
with IQ Gateway.
—
Device Scan Button: Press to start/stop 15-minute scan for microinverters over
the power line.
IQ Gateway LED States
LED
State
Description
All
Flashing amber in unison
The IQ Gateway is booting up
Flashing green sequentially
Software upgrade in progress
Network
Communications
Solid green
Communicating with Enphase Installer App
Flashing green
WPS connection in progress or the IQ
Gateway is attempting to connect to
Enphase Installer App
Solid amber
Local network connection only
Off
No network connection
AP mode
Solid green
AP mode enabled:
IQ Gateway Wi-Fi network available
Off
AP mode disabled:
IQ Gateway Wi-Fi network unavailable
Power
production
Solid green
All communicating devices are producing
Flashing green
Device upgrade in progress
Solid Amber
At least one device is not producing
Off
Devices are not producing or
communicating (low light or night time)
Device
Communications
Solid Green
All devices are communicating
Flashing Green
Device scan in progress
Solid Amber
At least one device is not communicating
Off
Devices are not
communicating (low light or
night time)

enphase Envoy-S Specifications

General

Model	Envoy-S
Category	Gateway
Communication	Wi-Fi, Ethernet, Cellular (optional)
Compatibility	Enphase Microinverters
Operating Temperature	-40°C to +65°C
Weight	1.1 lbs (0.5 kg)
Enclosure Rating	NEMA 3R
Power Supply	120/240 VAC
