Technical Data
Model Numbers
IQ Gateway Metered ENV-
S-EM-230
Enphase communications gateway with integrated single phase PV and
consumption metering. PV production metering and optional consumption
monitoring.
Accessories (order separately)
Current transformers
(CTs) CT-100-SPLIT-
ROW
WxHxD: 61 mm x 51 mm x 35 mm.
Lead length 4 m, extendable to 213 m depending on wire
size. Order extra CTs if monitoring multiple phases.
Enphase Mobile
Connect™ CELLMODEM-
02
Plug and play industrial grade cellular modem with five-year data plan for
systems up to 60 microinverters. (Available where there is adequate mobile
service in the installation area.)
Wire / Power Requirements / Specifications
Power
230 VAC or 400Y/230 VAC, 50 Hz. Max 20 A overcurrent protection required.
When hard wired outdoors, the IQ Gateway must be installed in an IP54
rated, or better, enclosure. (Use an appropriately rated enclosure if hard-
wiring indoors.) The supply wiring must be 2.5 mm
2
copper rated to 75º C or
better, and it must be protected by a max 20 A breaker
Capacity
Number of Enphase
Microinverters olled
Up to 600
Number of Enphase
AC Batteries polled
Up to 39
Mechanical Data
Dimensions (WxHxD)
213 x 126 x 45 mm
Weight
0.5 kg
Environmental Data
Ambient temperature range
-40° to 46° C when installed in an IP54-rated enclosure
Relative humidity
95%
Environmental rating
IP30. For installation indoors, or when hard wired outdoors, the IQ Gateway
must be installed in an IP54 rated, or better, enclosure. Use an appropriately
rated enclosure if hard-wiring indoors .
Altitude use
To 2000 meters
Cooling
Natural convection
Internet Connection Options
Integrated Wi-Fi
802.11b/g/n (2.4 GHz, 5 GHz)
Ethernet
Optional, 802.3, Cat5E (or Cat 6) UTP Ethernet cable (not included). If used,
must be fitted with included ferrite bead.
Mobile network
Optional, CELLMODEM-02 (not included)
