HCS Installation and Operation Manual
Line input power 240 VAC single-phase - L1, L2, and Safety Ground.
Voltage and wiring
208 VAC 3-phase wye-connected - Any two phases and Safety Ground. 240 VAC 3-phase, delta-connected.
With center-tap on one leg, you must use only the two phases on either side of the center-tap.
The two phases must both measure 120 VAC to ground. Do not use the third leg (208V “Stinger”).
Supplied input
Pre-installed supplied input conductors of the HCS-40R: L1, L2 and Ground use 3 ft of 10 AWG, 90ºC copper wire. Pre-installed
supplied input conductors of the HCS-50R, HCS-60R, and HCS-80R: L1, L2, and Ground use 3 ft of 8 AWG, 90ºC copper wire.
Frequency 50/60 Hz
CCID 20 mA
Specications
Note: The maximum current for the vehicle is set by the duty cycle of the Pilot waveform. Output power is variable
depending upon the HCS model and vehicle demand.
Current and output power
(at 240 VAC)
HCS Model
Number
Circuit
Breaker
Max
Current
Output
Power
Cable
Length
HCS-40R (hardwired) 40 A 32 A 7.7 kW 25 ft (7.6 m)
HCS-40PR + (6-50 plug) 40 A/50 A 32 A 7.7 kW 25 ft (7.6 m)
HCS-40PR + (14-50 plug) 40 A/50 A 32 A 7.7 kW 25 ft (7.6 m)
HCS-50R (hardwired) 50 A 40 A 9.6 kW 25 ft (7.6 m)
HCS-50PR + (6-50 plug) 50 A 40 A 9.6 kW 25 ft (7.6 m)
HCS-50PR + (14-50 plug) 50 A 40 A 9.6 kW 25 ft (7.6 m)
HCS-60R (hardwired) 60 A 48 A 11.5 kW 25 ft (7.6 m)
HCS-80R (hardwired) 80 A 64 A 15.4 kW 25 ft (7.6 m)
Plugs
An attached NEMA 6-50P or NEMA 14-50P plug is available on plug-type EVSE units.
A suitable receptacle is also supplied - please review the manual for proper installation guidelines.
Dimensions
Dimensions are for the enclosure only:
Height: 19.7 inches (500 mm)
Width: 8.9 inches (226 mm)
Depth: 5.3 inches (135 mm)
Weight
HCS-40R or HCS-40PR with 40A SAE J1772 connector and 25' length of cable: 6.1kg (13.5 lbs)
HCS-50R or HCS-50PR with 40A SAE J1772 connector and 25' length of cable: 6.3kg (14 lbs)
HCS-60R with 48A SAE J1772 connector and 25' length of cable: 9.0 kg (21 lbs)
HCS-80R with 64A SAE J1772 connector and 25' length of cable: 9.0 kg (21 lbs)
Environment
Operating temperature: -22°F to 122°F (-30°C to 50°C)
Storage temperature: -40°F to 176°F (-40°C to 80°C)
Enclosure rating NEMA 4 - watertight
Agency approvals ETL Listed, FCC Part 15 Class B, ENERGY STAR
®
Certied NOM (for particular models)
