About This Guide
Welcome to the Enterasys Matrix
®
N7 7C107 Chassis Hardware Installation Guide. This guide
lists the features and options of theN7 7C107 chassis and explains how to remove and reinstall its
fan tray, install the cable management bar, and power supplies.
USING THIS GUIDE
Read through this guide completely to familiarize yourself with its contents and to gain an
understanding of the features and capabilities of the N7 chassis. A general working knowledge of
data communications networks is helpful when setting up the Enterasys Matrix N7 7C107 chassis.
STRUCTURE OF THIS GUIDE
This guide is organized as follows:
This preface provides preliminary information to help you use this guide and a brief summary of
each chapter. It also discusses the Matrix N7 Series manual set and defines conventions used
throughout this document.
Chapter 1, Introduction, describes the features and capabilities of the N7 chassis, and how to get
help.
Chapter 2, Installation Requirements and Guidelines, lists the installation site requirements that
must be met before installing the N7 chassis in a cabinet or rack. This chapter also includes
configuration guidelines, and operating specifications for the N7 chassis enclosure and power
supply modules.
Chapter 3, Enterasys Matrix N7 Chassis Setup, contains instructions for a standalone or
rackmount installation of the N7 chassis. It also provides instructions for installing the cable
management bar, installing the power supply modules, removing and reinstalling the fan tray, and
powering up the N7 chassis.
Appendix A, Specifications and Regulatory Compliance, lists environmental and operating
specifications for the N7 chassis and power supply modules.
Note: In this guide, the Enterasys Matrix N7 7C107 chassis is also referred to as the
Matrix N7, the N7 chassis, or simply the chassis.
