Enterasys Matrix N7 7C107 - The N7 7 C107 Chassis with Redundant Power Supplies

Overview
1-2 Introduction
Figure 1-1 The N7 7C107 Chassis with Redundant Power Supplies
1 Chassis (7C107) 3 Fan tray (6C407)
2 Module slots (7 total) 4 Redundant power supplies (6C207-3) (2)
